PLL602-11
96MHz – 200MHz Low Phase Noise PECL XO (12 – 25MHz Crystals)
47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 09/03/04 Page 3
3. General Electrical Specifications
PARAMETERS
SYMBOL
CONDITIONS
MIN.
TYP.
MAX.
UNITS
Supply Current, Dynamic
(with Loaded Outputs)
IDD
PECL
80
mA
Operating Voltage
VDD
2.97
3.63
V
Output Clock Duty Cycle
@ VDD – 1.3V (PECL)
45
50
55
%
Short Circuit Current
±50
mA
4. Jitter and Phase Noise Specification
PARAMETERS
CONDITIONS
MIN.
TYP.
MAX.
UNITS
Period jitter RMS
With capacitive decoupling
between VDD and GND.
4
ps
Accumulated jitter RMS
With capacitive decoupling
between VDD and GND. Over
10,000 cycles.
9
ps
Phase Noise relative to carrier
155MHz @100Hz offset
-95
dBc/Hz
Phase Noise relative to carrier
155MHz @1kHz offset
-120
dBc/Hz
Phase Noise relative to carrier
155MHz @10kHz offset
-125
dBc/Hz
Phase Noise relative to carrier
155MHz @100kHz offset
-121
dBc/Hz
