PLL701-26

Low EMI Spread Spectrum Multiplier Clock

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991

www.phaselink.com

Rev 08/12/04 Page 2

PIN DESCRIPTIONS

Name

Number

Type

Description

FIN

1

I

Input Clock Frequency. ( 33 ~ 90MHz )

CLK2

2

O

Buffered Clock Output. 1X the input frequency ( FIN ).

CLK1

3

O

Buffered Clock Output. 1X the input frequency ( FIN ).

GND

4

I

Ground.

CLK3

5

O

Buffered Clock Output. 1X the input frequency ( FIN ).

VDD

6

P

3.3V Power Supply.

CLK4

7

O

Buffered Clock Output. 1X the input frequency ( FIN ).

CLK5

8

O

Buffered Clock Output. 1X the input frequency ( FIN ).

ELECTRICAL SPECIFICATIONS

1. Absolute Maximum Ratings

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage

4.6

V

Input Voltage, dc

-0.5

V

Output Voltage, dc

-0.5

V

Storage Temperature

-65

150

°C

Ambient Operating Temperature*

-40

85

°C

Junction Temperature

125

°C

Lead Temperature (soldering, 10s)

260

°C

ESD Protection, Human Body Model

2

kV

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the

device and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other

conditions above the operational limits noted in this specification is not implied.

* Note: Operating Temperature is guaranteed by design for all parts (COMMERCIAL and INDUSTRIAL), but tested for COMMERCIAL grade only.

2. Electrical Characteristics

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Supply Voltage

2.97

3.63

V

Input Low Voltage

0.8

V

Input High Voltage

2.0

V

Input Low Current

19

50.0

µA

Input High Current

0.10

100.0

µA

Output Low Voltage

0.25

0.4

V

Output High Voltage

2.4

2.9

V

Supply Current

Unloaded outputs at 75MHz,

30.0

40.0

mA
