Sensor output interface terminal

KCD2-R

< Relay output with 1 pole, yellow LED indicates switching state

< Free-wheeling diode

< Compact terminal housing

< Clips onto standard 35 mm rail to DIN EN 50 022

< Degree of protection IP20

Sensor output interface terminals with relay output

Dimensions

40

20

5

4

6

2

1

3

LED

Technical Data

Functional safety related parameters

MTTFd

19699 a

Indicators/operating means

LED yellow

switch output

Electrical specifications

Operating voltage

UB

24 V DC ± 15 %

Ripple

≤ 10 %

Operating current

IB

16 mA

Input

1

Germany: +49 621 776 1111

Pepperl+Fuchs Group

Refer to "General Notes Relating to Pepperl+Fuchs Product Information".

USA: +1 330 486 0001

Singapore: +65 6779 9091

www.pepperl-fuchs.com

fa-info@us.pepperl-fuchs.com

fa-info@sg.pepperl-fuchs.com

fa-info@de.pepperl-fuchs.com
