Wire-wound Chip Inductors - Open

www.ctparts.com

CT1008LDLSF

Series

From 0.9µH to 10µH

SPECIFICATIONS

Please specify tolerance code when ordering.

CT1008LDLSF-1R3_

J = ±5%, K = ±10%

Test

Q

SRF

DCR

IDC

Irms

Part

Ind.

Freq.

Fact.

Min.

Max.

Typ.

Max.

Tol.

Number

(µH)

(MHz)

Typ.

(MHz)

(W)

(mA)

(mA)

(%)

CT1008LDLSF-R90K

0.9

2.5

25

300

0.1

1400

1300

10

CT1008LDLSF-1R1K

1.1

2.5

24

275

0.105

1300

1200

10

CT1008LDLSF-1R3_

1.3

2.5

24

220

0.11

1200

1100

5 / 10

CT1008LDLSF-1R5_

1.5

2.5

22

210

0.125

1100

1000

5 / 10

CT1008LDLSF-1R9_

1.9

2.5

22

165

0.14

1000

1000

5 / 10

CT1008LDLSF-2R2_

2.2

2.5

21

75

0.155

950

950

5 / 10

CT1008LDLSF-2R7_

2.7

2.5

22

57

0.19

800

900

5 / 10

CT1008LDLSF-3R3_

3.3

2.5

21

54

0.21

750

800

5 / 10

CT1008LDLSF-3R9_

3.9

2.5

21

50

0.22

700

800

5 / 10

CT1008LDLSF-4R7_

4.7

2.5

27

48

0.435

700

650

5 / 10

CT1008LDLSF-5R8_

5.8

2.5

21

33

0.28

550

750

5 / 10

CT1008LDLSF-6R8_

6.8

2.5

20

28

0.315

500

700

5 / 10

CT1008LDLSF-8R2_

8.2

2.5

20

24

0.395

500

650

5 / 10

CT1008LDLSF-100_

10

2.5

22

20

0.48

450

550

5 / 10

Not Shown at Actual Size

CHARACTERISTICS

PHYSICAL DIMENSIONS

Description: SMD ferrite core wire-wound chip inductor. Low

DC resistance.

Applications: LC resonant circuits such as oscillator and signal

generators, impedance matching, circuit isolation, RF filters, disk

drives and computer peripherals, audio and video equipment, TV,

radio and telecommunication equipment.

Operating Temperature: -25°C to 105°C (including self -

temperature rise)

IDC: For inductance drop 10% from its value with current.

Irms: For a 40°C temperature rise from 25°C ambient with

current.

Inductance Tolerance: ±5% & ±10%

Testing: Inductance and Q are tested on an Agilent E4991A/

HP4287A+16197A

Packaging: Tape & Reel.

Miscellaneous: RoHS Compliant.

Additional Information: Additional electrical & physical

information available upon request

Samples available. See website for ordering information.

A

B

C

D

E

F

G

Max.

Max.

Max.

2.99

2.50

2.20

2.03

0.51

1.52

0.70

0.118

0.098

0.087

0.080

0.020

0.060

0.028

Size

mm

inches

2.54

1.02

1.02

1.27

Unit: mm

PAD LAYOUT
