Power Inductors - Shielded

www.ctparts.com

CTLVC6020F

Series

From 0.5µH to 22µH

SPECIFICATIONS

Please specify inductance tolerance code when ordering.

CTLVC6020F-1R5_

M = ±20%, N = ±30%

*Isat: DC current (A) that will cause L to drop approximately 30%.

**Irms: DC current (A) that will cause an approximate

ΔT of 40°C.

L Test

DCR

*Isat

**Irms

Part

Inductance

Freq.

±30%

Typ.(Max.)

Typ.(Max.)

Number

(µH)

(kHz)

(m

Ω)

(A)

(A)

CTLVC6020F-R50N

0.5

100

13

8.0(7.20)

5.3(4.77)

CTLVC6020F-R90N

0.9

100

18

6.3(5.67)

4.2(3.78)

CTLVC6020F-1R0N

1.0

100

19

6.2(5.58)

4.1(3.69)

CTLVC6020F-1R5_

1.5

100

26

5.0(4.50)

3.6(3.24)

CTLVC6020F-2R2_

2.2

100

34

4.2(3.78)

3.2(2.88)

CTLVC6020F-3R3_

3.3

100

40

3.2(2.88)

2.7(2.43)

CTLVC6020F-4R7_

4.7

100

58

2.5(2.25)

2.2(1.98)

CTLVC6020F-6R8_

6.8

100

85

2.2(1.98)

1.8(1.62)

CTLVC6020F-100_

10

100

125

2.0(1.80)

1.6(1.44)

CTLVC6020F-150_

15

100

190

1.3(1.17)

1.3(1.17)

CTLVC6020F-220_

22

100

260

1.1(0.99)

1.1(0.99)

Not Shown at Actual Size

CHARACTERISTICS

PHYSICAL DIMENSIONS

PAD LAYOUT

Description: SMD power inductors sealed with magnetic resin.

Applications: Smart phones, DSC, Tablet PC’s, DC/DC convert-

ers, etc.

Operating Temperature: -55°C to 125°C (including

self - temperature rise)

Inductance Tolerance: ±20%, ±30%

Testing: Inductance is tested on an HP4284A at 100kHz, 1V

Packaging: Tape & Reel.

Marking: Parts are marked with inductance code.

Additional Information: Additional electrical & physical

information available upon request.

Samples available. See website for ordering information.

A

BC

D

D

Magnetic Shielding

5.7

1.6

2.9

1.6

Size

mm

inches

CTLVC6020F-1R0N

1.0

100

19

6.2(5.58)

4.1(3.69)

CTLVC6020F-1R5_

1.5

100

26

5.0(4.50)

3.6(3.24)

CTLVC6020F-2R2_

2.2

100

34

4.2(3.78)

3.2(2.88)

CTLVC6020F-3R3_

3.3

100

40

3.2(2.88)

2.7(2.43)

CTLVC6020F-4R7_

4.7

100

58

2.5(2.25)

2.2(1.98)

CTLVC6020F-6R8_

6.8

100

85

2.2(1.98)

1.8(1.62)

Unit: mm

A

B

C

D

6.0±0.2

6.0±0.2

1.7±0.3

0.236±0.008

0.236±0.008

0.067±0.012
