09/12/2020   Page 3 / 12

Distribution block - PTFIX 2X4 RD - 1028362

Technical data

General

Number of shocks per direction

3

Test directions

X-, Y- and Z-axis (pos. and neg.)

Relative insulation material temperature index (Elec., UL 746 B)

130 °C

Temperature index of insulation material (DIN EN 60216-1 (VDE

0304-21))

130 °C

Static insulating material application in cold

-60 °C

Surface flammability NFPA 130 (ASTM E 162)

passed

Specific optical density of smoke NFPA 130 (ASTM E 662)

passed

Calorimetric heat release NFPA 130 (ASTM E 1354)

28 MJ/kg

Smoke gas toxicity NFPA 130 (SMP 800C)

passed

Fire protection for rail vehicles (DIN EN 45545-2) R22

HL 1 - HL 3

Fire protection for rail vehicles (DIN EN 45545-2) R23

HL 1 - HL 3

Fire protection for rail vehicles (DIN EN 45545-2) R24

HL 1 - HL 3

Fire protection for rail vehicles (DIN EN 45545-2) R26

HL 1 - HL 3

Dimensions

Width

6.2 mm

Length

28.6 mm

Height

21.7 mm

Connection data

Connection method

Push-in connection

Stripping length

10 mm ... 12 mm

Conductor cross section solid min.

0.2 mm²

Conductor cross section solid max.

6 mm²

Conductor cross section AWG min.

24

Conductor cross section AWG max.

10

Conductor cross section flexible min.

0.2 mm²

Conductor cross section flexible max.

4 mm²

Min. AWG conductor cross section, flexible

24

Max. AWG conductor cross section, flexible

10

Conductor cross section flexible, with ferrule without plastic sleeve min. 0.2 mm²

Conductor cross section flexible, with ferrule without plastic sleeve max. 4 mm²

Conductor cross section flexible, with ferrule with plastic sleeve min.

0.2 mm²

Conductor cross section flexible, with ferrule with plastic sleeve max.

4 mm²

Connection cross sections directly pluggable

0.5 mm² 6 mm²

Conductor cross section solid min.

0.5 mm²

Conductor cross section solid max.

6 mm²

Conductor cross section flexible, with ferrule without plastic sleeve min. 0.75 mm²

Conductor cross section flexible, with ferrule without plastic sleeve max. 4 mm²

Conductor cross section flexible, with ferrule with plastic sleeve min.

0.5 mm²

Conductor cross section flexible, with ferrule with plastic sleeve max.

4 mm²
