Datasheet

HDP Industrial Series

Remote Adhesive-Mount Dual-Band WiFi Antenna

Ordering Information

Part Number

Description

ANT-2/5-HDP-2000-SMA

Remote adhesive-mount dual-band WiFi antenna with 2 m of RG-174/U low-loss coaxial

cable terminated in an SMA plug (male pin)

ANT-2/5-HDP-2000-RPS

Remote adhesive-mount dual-band WiFi antenna with 2 m of RG-174/U low-loss coaxial

cable terminated in an RP-SMA plug (female socket)

Available from Linx Technologies and select distributors and representatives.

The Linx HDP industrial series offers rugged remote-

mount dipole antennas having excellent performance

for single- and dual-band WiFi/WLAN as well as

other 2.4 GHz or 5 GHz ISM and U-NII frequency

band applications.

The dual-band HDP industrial antennas are durable,

low profile, IP67 ratable, and UV protected. They

mount permanently to non-conductive surfaces

using the integrated adhesive patch and connect

using 2 meters of RG-174/U low-loss cable

terminated in an SMA plug (male pin), or RP-SMA

plug (female socket) connector for FCC Part 15

compliant applications.

Features

• Performance at 2.4 GHz

― VSWR: ≤ 1.5

― Peak Gain: 4.3 dBi

― Efficiency: 37%

• Performance at 5 GHz

― VSWR: ≤ 1.4

― Peak Gain: 2.3 dBi

― Efficiency: 15%

• Low profile

― 104.0 mm x 17.0 mm x 4.2 mm

• Durable UV protected enclosure rated at IP67 for

heavy-duty outdoor use

• Low-loss RG-174/U coaxial cable for improved

performance at higher frequencies

• SMA plug (male pin), or RP-SMA plug (female

socket) connector

Applications

• Single- and dual-band WiFi/WLAN

― 802.11b/g

― WiFi 4 (802.11n)

― WiFi 5 (802.11ac)

― U-NII bands 1-4

• ISM Applications:

• Internet of Things (IoT) devices

• Smart Home networking

• Sensing and remote monitoring
