1.9kW Single-Phase Switched PDU, LX Interface,

120V Outlets (8 5-15/20R), NEMA L5-20P/5-20P

input, 12 ft. (3.66 m) Cord, 1U Rack, TAA

MODEL NUMBER: PDUMH20NET2LX

1.9kW 1U PDU distributes, monitors and manages AC power in an IT environment. Built-in Java-free

network interface helps you remotely monitor load levels to prevent overloads that cause downtime.

Description

The PDUMH20NET2LX 1.9kW Single-Phase Switched PDU provides advanced network control and

remote power monitoring with the ability to turn on, turn off, reboot or lock out power to each outlet. By

reducing the frequency of on-site visits, these advanced remote capabilities can save you money and

reduce downtime.

The 1U PDU features eight switched NEMA 5-15/20R outlets with an included cord retention bracket to

prevent cables from becoming accidentally disconnected. A 12-ft. (3.66 m) cord with NEMA L5-20P plug

and 5-20P plug adapter connects the PDU to a compatible AC power source, generator or protected UPS.

The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU

status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports

10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2

modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported

include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and

NTP.

A digital ammeter allows you to monitor the total load in real time to ensure it remains well below

maximum capacity with no danger of overload. The single-phase PDU installs in 1U of space in EIA-

standard 19-inch racks. You can also mount it vertically in 0U of rack space or on a wall or under a

counter with the included brackets and user-supplied screws.

Features

Distributes, Monitors and Manages Network-Grade AC Power1.9kW 120V switched PDU with single-

phase inputRecommended for network applications requiring individual outlet control, load shedding and

remote monitoring of critical network componentsNEMA L5-20P plug with 12-ft. (3.66 m) cord and 5-20P

plug adapter connects to compatible AC power sourceFirmware upgrades support future product

enhancementsDigital ammeter reports total PDU load in real time

8 Switched NEMA 5-15/20R Outlets Distribute AC PowerIndividual outlets can be remotely controlled

to power up, power down, reboot or lock out devicesCord retention bracket prevents cables from

becoming accidentally disconnectedIndividual LEDs indicate which outlets are live

Built-In LX Platform InterfacePre-installed WEBCARDLX with the latest version of PowerAlert Device

Manager firmware (PADM20) provides enhanced remote management capabilitiesPADM20 and

PowerAlert Element Manager (PAEM) form a powerful tool for expanding maintenance functions in large

Highlights

1.9kW 120V single-phase

switched 1U PDU

q

8 individually controllable NEMA

5-15/20R outlets

q

Pre-installed WEBCARDLX with

latest version of PADM20 for IP-

based Auto Probe feature

q

Digital ammeter for on-site load

monitoring in real time

q

NEMA L5-20P input with 12-ft.

(3.66 m) AC power cord and 5-

20P adapter

q

Package Includes

PDUMH20NET2LX 1.9kW

Single-Phase Switched PDU

q

Built-in LX Platform interface

q

Configuration cable

q

(8) Cable ties

q

Cord retention bracket

q

Mounting hardware

q

Owner’s manual

q
