MS6-LOE-1/2-R 数据表(PDF) 1 Page - Festo Corporation. |
|
|
|||||||||||||||||||||||||||||
MS6-LOE-1/2-R 数据表(HTML) 1 Page - Festo Corporation. |
|
|
1 / 1 page  Air line lubricator MS6-LOE-1/2-R Part number: 529775 Data sheet Feature Value Size 6 Series MS Mounting position Vertical +/- 5° Structural design Proportional standard oil mist lubricator Max. oil capacity 75 cm³ Bowl guard Plastic bowl guard Symbol 00991532 Operating pressure 1 bar ... 16 bar Minimum flow rate for lubricator function 50 l/min Standard nominal flow rate 7200 l/min Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas Information on operating and pilot media Operation with oil lubrication possible Corrosion resistance class (CRC) 2 - Moderate corrosion stress Storage temperature -10 °C ... 60 °C For use in the food industry See supplementary material information Temperature of medium -10 °C ... 60 °C Oil viscosity ISO VG 32 Ambient temperature -10 °C ... 60 °C Product weight 600 g Type of mounting Optionally: Line installation With accessories Pneumatic connection 1 G1/2 Pneumatic connection 2 G1/2 Note on materials RoHS-compliant Housing material Die-cast aluminum Material of bowl PC 3/23/22 - Subject to change - Festo SE & Co. KG 1/1 |
