Dimensions

Unit: mm

Packing List

Part Number

Description

EPC-R3220

EPC-R3220 with 1GDDR/8GeMMC

1652008019-01

2x10P/2.54 Terminal Plug for COM/GPIO

1652005203

2P 90D(F) Plug-in block for power in

External I/O

EPC-R3220

Ordering Information

Part Number

CPU

Memory

eMMC

SD

Serial

GPIO

USB OTG

LAN

Wi-Fi

TPM

Operating

Temperature

Add-on

EPC-R3220IS-OLA1E

TI AM3352

1GB

8GB

1

1

1

1

1

-

-

-20 ~ 70 °C

DeviceOn

EPC-R3220IS-OLA1KE

TI AM3352

1GB

8GB

1

1

1

1

1

1

1

-20 ~ 70 °C

DeviceOn

EPC-R3220IS-OMA1E

TI AM3352

1GB

8GB

1

1

1

1

1

-

-

-20 ~ 70 °C

CommBridge*

EPC-R3220IS-OMA1KE

TI AM3352

1GB

8GB

1

1

1

1

1

1

1

-20 ~ 70 °C

CommBridge*

*CommBridge only for China

Optional Accessories

Part Number

Description

96PSA-A36W12R1-3

ADP A/D 100-240V 36W 12V

1700023307-01

DC jack/plug-in cable 1*2P-5.0 10 cm RSB-4220

170203183C

Power cord 3P Europe (WS-010+WS-083) 183 cm

170203180A

Power cord 3P UK 2.5A/3A 250 V 1.83 M

1700001524

Power cord 3P UL 10A 125 V 180 cm

1700019146

Power cord CCC 3P 10A 250V 183cm

ROM-ED20-00A1E

Debug adapter board

1700020442-01

Debug port cable

1700023619-01

USB OTG cable_typeA M to mirco USB

1950016423T101

DIN RAIL(BLACK WEAVE)ASS'Y FOR ICE-3105

1960056982T003

MOUNTING BRACKET 2U2X DS-780

1750008800-01

Cable Ant.SMA/F-R-BH MFH4/113 BLK L100

1750008772-01

2Dipole Ant.D.B 2.4+5G WIFI 3/4.4dBi SMA/M-R BLK

968AD00479*

EC20CEFAG-MINIPCIE R2.1 LTE Cat 4 for China

1750008424-01

LTE Antenna Dipole L=148.5mm 4dBi A9703021

1750008461-01

Cable Ant. SMA/F-R-BH R/A MHF/113 WHT L83

WWAN1

1930007942

Screw for Wallmount (x4) and DinRail (x3)

1930006668-01

Screw for Mini-PCIE module

* Please contact us to get suitable LTE solution for your region.

160.40

137

167.90

181.40

LAN1

RS232/485x2

GPIOx6

Power on

LAN2

DC-In

Programmable
