Model number

VAZ-R4-R2

RS 232C/RS 485 converter

Features

• Direct connection to a PC (RS 232)

• Point to point connection only

Electrical connection

Technical data

Electrical specifications

Power supply

draws its power supply from RS 232 interface of the PC

Pin 4 (DTR) must be permanently high.

Interface

Interface type

Standard PC RS 232 interface with 9-pin D-SUB connector

(female)

RS 485 interface with 9-pin D-SUB connector (male)

Transfer rate

up to 57600 Bit/s

Cable length

for RS 232 and RS 485 each max. 2 m

Ambient conditions

Ambient temperature

0 ... 55 °C (32 ... 131 °F)

Storage temperature

-25 ... 70 °C (-13 ... 158 °F)

Mechanical specifications

Connection

RS 232 , RS 485

Dimensions

63, 54, 17 mm (L, W, H)

Notes

The interface converter VAZ-R4-R2 is the ideal interface converter between the RS 232C inter-

face of the PC and the RS 485 interface of the AS-Interface Gateway.

The converter requires no additional external power supply. For this reason, it is highly suitable

for mobile use on a laptop computer or notebook.

The RS 232C/RS 485 converter is simply plugged between the AS-Interface Gateway and the

RS 232 connection cable. Only one device with an RS 485 interface can be connected up to

the interface converter.

The RS 232C/RS 485 converter can be used on various operating systems. By means of the

AS-i Control Tools for Windows an AS-Interface Master with an RS 485 interface can be opera-

ted as well as an AS-Interface Master with an RS 232 interface. The RS 232C/RS 485 conver-

ter supports all transmission rates up to 57600 Bit/s.

Sub-D socket

RS 232C

Sub-D connector

RS 485

µP

GND

DTR

TxD

RxD

CTS

RTS

A

B

5

4

3

2

8

7

3

8

12345

6789

54321

9876
