Product data sheet

Specifications

Analog output module, Modicon

TM5, 2O, +/-10 V/0 to 20mA, 16bits

TM5SAO2H

Main

Range of product

Modicon TM5

Product or component type

Analog output module

Analogue output number

2

Analogue output resolution

15 bits + sign, +/- 10 V

15 bits, 0...20 mA

Complementary

Range compatibility

Modicon LMC058

Modicon M258

Product compatibility

Logic controller

Motion controller

Analogue output type

Current 0...20 mA

Voltage +/- 10 V

Measurement resolution

305.176 µV, +/- 10 V

610.352 nA, 0...20 mA

Colour

White

Response time

<= 1 ms

Minimum output impedance

1 Ohm

Sampling duration

50 ms

Measurement error

< 0.045 % of full scale +/- 10 V at 25 °C

< 0.045 % of full scale 0...20 mA at 25 °C

Temperature coeﬃcient

0.015 %FS/°C, analogue output type: current

0.015 %FS/°C, analogue output type: voltage

Non-linearity

< 0.007 %FS/°C, analogue output type: current

< 0.007 %FS/°C, analogue output type: voltage

Type of cable

Shielded cable

Isolation

No insulation between channels

500 Vrms AC insulation between channel and bus

Supply

Internal

[Us] rated supply voltage

24 V DC -15...20 %

Local signalling

1 LED green for power supply

1 LED red for power supply

2 LEDs yellow for output status

Current consumption

2 mA at 5 V DC bus

50 mA at 24 V DC input/output

Apr 6, 2022
