PDIP−8

CASE 626−05

ISSUE P

DATE 22 APR 2015

SCALE 1:1

14

5

8

b2

NOTE 8

D

b

L

A1

A

eB

XXXXXXXXX

AWL

YYWWG

E

GENERIC

MARKING DIAGRAM*

XXXX

= Specific Device Code

A

= Assembly Location

WL

= Wafer Lot

YY

= Year

WW

= Work Week

G

= Pb−Free Package

*This information is generic. Please refer to

device data sheet for actual part marking.

Pb−Free indicator, “G” or microdot “ G”,

may or may not be present.

A

TOP VIEW

C

SEATING

PLANE

0.010

CA

SIDE VIEW

END VIEW

END VIEW

WITH LEADS CONSTRAINED

DIM

MIN

MAX

INCHES

A

−−−−

0.210

A1

0.015

−−−−

b

0.014

0.022

C

0.008

0.014

D

0.355

0.400

D1

0.005

−−−−

e

0.100 BSC

E

0.300

0.325

M

−−−−

10

−−−

5.33

0.38

−−−

0.35

0.56

0.20

0.36

9.02

10.16

0.13

−−−

2.54 BSC

7.62

8.26

−−−

10

MIN

MAX

MILLIMETERS

NOTES:

1. DIMENSIONING AND TOLERANCING PER ASME Y14.5M, 1994.

2. CONTROLLING DIMENSION: INCHES.

3. DIMENSIONS A, A1 AND L ARE MEASURED WITH THE PACK-

AGE SEATED IN JEDEC SEATING PLANE GAUGE GS−3.

4. DIMENSIONS D, D1 AND E1 DO NOT INCLUDE MOLD FLASH

OR PROTRUSIONS. MOLD FLASH OR PROTRUSIONS ARE

NOT TO EXCEED 0.10 INCH.

5. DIMENSION E IS MEASURED AT A POINT 0.015 BELOW DATUM

PLANE H WITH THE LEADS CONSTRAINED PERPENDICULAR

TO DATUM C.

6. DIMENSION eB IS MEASURED AT THE LEAD TIPS WITH THE

LEADS UNCONSTRAINED.

7. DATUM PLANE H IS COINCIDENT WITH THE BOTTOM OF THE

LEADS, WHERE THE LEADS EXIT THE BODY.

8. PACKAGE CONTOUR IS OPTIONAL (ROUNDED OR SQUARE

CORNERS).

E1

0.240

0.280

6.10

7.11

b2

eB

−−−−

0.430

−−−

10.92

0.060 TYP

1.52 TYP

E1

M

8X

c

D1

B

A2

0.115

0.195

2.92

4.95

L

0.115

0.150

2.92

3.81

°

°

H

NOTE 5

e

e/2

A2

NOTE 3

M

NOTE 6

M

STYLE 1:

PIN 1. AC IN

2. DC + IN

3. DC − IN

4. AC IN

5. GROUND

6. OUTPUT

7. AUXILIARY

MECHANICAL CASE OUTLINE
