www.littelfuse.com

Power Distribution Centers

TERMINAL TYPE 6

TERMINAL TYPE 7

Ratings

Part Number

Description

Wire Diam.

Material

913-772 (Reeled per 2500 pcs)

Female

0.5-0.8 mm²/18-20AWG

Tin plated brass

0913772001 (Single per 250 pcs)

0.5-0.8 mm²/18-20AWG

913-773 (Reeled per 2500 pcs)

Female

1.33-2.09 mm²/14-16AWG

Tin plated brass

0913773001 (Single per 250 pcs)

1.33-2.09 mm²/14-16AWG

913-774 (Reeled 2000 pcs)

Female

3.32-5.37 mm²/10-12AWG

Tin plated brass

0913774001 (Single per 250 pcs)

3.32-5.37 mm²/10-12AWG

Ratings

Part Number

Description

Wire Diam.

Material

09130075Z (Per 20 pcs)

Bus bar 2 position

5.0-8.0 mm²/8-10AWG

Copper

09130076Z (Per 20 pcs)

Bus bar 4 position

5.0-8.0 mm²/8-10AWG

Copper

09130077Z (Per 20 pcs)

Bus bar 7 position

5.0-8.0 mm²/8-10AWG

Copper
