.xx = .02

.xxx = .010

•

•

4

-5V

A

5

0V

B

278

6

1

GND

••

RF2

3

RF1

RF IN

Switching Table

A

B

Function

0V

-5V

RF IN-RF2

-5V

0V

RF IN-RF1

Parameter

Min Typ

Max Units

Conditions

Operating Frequency

DC

2000

MHz

Control Voltage

See Table

Insertion Loss

0.5

0.8

dB

DC - 1000 MHz

0.6

0.9

dB

1000 - 2000 MHz

Isolation

30

35

dB

DC - 1000 MHz

21

25

dB

1000 - 2000 MHz

VSWR

Input

1.1/1

1.2/1

Impedance

50

OHMS

Transition (Rise/Fall) Time

3

nSEC

Intercept Points

3rd

46

dBm

RF Power

Operate

+27

+23

dBm

1.0 dB Comp. Above 100 MHz

Operating Temperature

-55

+25

+85

°CTA

Note: A/C Couple Capacitors may be required for your Application

GUARANTEED PERFORMANCE

TYPICAL PERFORMANCE

at 25 °C

10

80

2.0

1.8

60

40

20

0.5

1.5

1.6

1.4

1.2

1.0

0

0

1.0

3000

1000

400

100

40

VSWR

I. LOSS

ISO

MODEL NO.

DS0702-R

GaAs SP2T

FEATURES

DC - 2000 MHz

Reflective

0.6 dB I.L., 25 dB Iso.

8 Pin Surface Mount Package

Very Low Cost

SP2T

D AICO

I ndustries

PART

.197

1

0.069

IDENTIFICATION

234

5

6

7

8

.016

.205

.244

.157

.050

.007

GAP

.005

Pin 1

Iss. 2

FREQUENCY (MHz)
