H

H–25

Dimensions are shown: Inch (mm)

Specifications and dimensions subject to change

www.ckswitches.com

ROHS

NO.

QUANTITY

PART NUMBER

POS.

DIM. ‘A’

DIM. ‘B’

PER TUBE

BPA01SB

1

.176 (4,48)

N/A

100

BPA02SB

2

.276 (7,0)

.100 (2,54)

60

BPA03SB

3

.376 (9,6)

.200 (5,08)

45

BPA04SB

4

.476 (12,1)

.300 (7,62)

35

BPA05SB

5

.575 (14,6)

.400 (10,16)

30

BPA06SB

6

.677 (17,2)

.500 (12,70))

25

BPA07SB

7

.776 (19,7)

.600 (15,24)

20

BPA08SB

8

.878 (22,3)

.700 (17,78)

20

BPA09SB

9

.976 (24,8)

.800 (20,32)

15

BPA10SB

10

1.075 (27,3)

.900 (22,86)

15

BPA12SB

12

1.280 (32,5)

1.100 (27,94)

14

Schematic

SPST

BPA Series

Side Actuated DIP Switches

Side Actuator – Surface Mount Terminals

BPA08SB

NOTE: Tape and reel packaging available by adding “R” to end of

project number.

ON

0.100

(2,54)

PITCH

0.236

(6,0)

0.033/0.041

(0,85/1,04)

0.063

0.024

(1,6+0/-0,2)

(0,6+0/-0,1)

1 2

3

4 5 6

7

8

C&K

BPA08

0.055

(1,4)

5B

0.083

(2,1)

0.029

(0,75)

0.173

(4,4)

0.321

(8,15)

0.039

(1,0)

0.366

“A”

“B”

0.031

(0,8)

0.010

(0,25)

1 2

3

4 5 6

7

8

0.031

(0,8)

(9,3)

6.11

10.41

2.54 TYP

1.52 MIN

TYP

"B"

SEE CHART

P.C. MOUNTING

Side Actuator – Thru-hole Terminals

BPA08B

NOTE: Reverse throw available, contact C&K for P/N and quote.

ROHS

NO.

QUANTITY

PART NUMBER

POS.

DIM. ‘A’

DIM. ‘B’

PER TUBE

BPA01B

1

.176 (4,48)

N/A

100

BPA02B

2

.276 (7,0)

.100 (2,54)

60

BPA03B

3

.376 (9,6)

.200 (5,08)

45

BPA04B

4

.476 (12,1)

.300 (7,62)

35

BPA05B

5

.575 (14,6)

.400 (10,16)

30

BPA06B

6

.677 (17,2)

.500 (12,70))

25

BPA07B

7

.776 (19,7)

.600 (15,24)

20

BPA08B

8

.878 (22,3)

.700 (17,78)

20

BPA09B

9

.976 (24,8)

.800 (20,32)

15

BPA10B

10

1.075 (27,3)

.900 (22,86)

15

BPA12B

12

1.280 (32,5)

1.100 (27,94)

14

Schematic

SPST

1

2

3

4

5

6

7

8

ON

0.100

(2,54)

PITCH

+.000

-.008

+.000

-.004

0.236

(6,0)

0.051

(1,3)

0.157

(4,0)

0.106

(2,7)

0.063

0.024

(1,6+0/-0,2)

(0,6+0/-0,2)

1

2

3

4

5

6

7

8

C&K

BPA08

0.055

(1,4)

5B

0.083

(2,1)

0.029

(0,75)

0.173

(4,4)

0.321

(8,15)

0.039

(1,0)

0.010

(0,25)

0.299/0.343

(7,6/8,7)

“A”

“B”

0.100

(2,54)

0.300

(7,6)

+.008

-.000

ø0.032

(0,8+0,2/-0)

“B”

13 feb 19
