Minmax's MAU300 DC/DC's are specially designed to

provide higher power to 2W in a miniature SIP package.

The series consists of 21 models with input voltages of

5V, 12V and 24VDC which offers standard output voltages of

3.3V, 5V, 12V, 15V, ±5V, ±12V and ±15VDC for a wide

choice.

The MAU300 series is an excellent selection for a variety

of applications including distributed power systems, mixed

analog/digital subsystems, portable test equipments, local

power networks and battery backed systems.

Industry Standard Pinout

Internal SMD Construction

UL 94V-0 Package Material

Temperature Performance -40] to +85]

Output 3.3, 5, 12, 15, {5, {12 and {15VDC

Input 5, 12 and 24VDC

Low Cost

MTBF > 2,000,000 Hours

1000VDC Isolation

Efficiency up to 83%

Key Features

2W, Miniature SIP, Single & Dual Output DC/DC Converters
