Ordering Information

ASIA

Units 2111-2116, Level 21

Tower1, Metroplaza

223, Hing Fong Road

Kwai Fong, New Territories

Hong Kong

Telephone: 852-2437-9662

Facsimile: 852-2402-4426

Model

Maximum Output

Maximum Peak

Number

Power

Voltage

Load

DPS52-M

30W

5V

6A

6.5A

±2%

50mV

DPS53-M

60W

12V

5A

5.4A

±2%

120mV

DPS54-M

60W

15V

4A

4.3A

±2%

150mV

DPS55-M

60W

24V

2.5A

2.7A

±2%

240mV

DPS58-M

60W

48V

1.25A

1.35A

±2%

480mV

1. Peak-to-peak with 20 MHz bandwidth and 10 µF tantalum capacitor in parallel with a 0.1 µF capacitor.

5.24"

(133.0)

78.7"

(2000±15)

MODEL LABEL

DC OUTPUT CABLE

INDICATOR LED

AC INLET

NOTES:

1. Specifications subject to change without notice.

2. All dimensions in inches (mm), tolerance is

3. Warranty: 1 year

4. Weight: 1.06 lb./ .48 kg

5. AC input power cord sold separately.

6. Specifications are for convection rating at factory settings

at 115VAC input, 25°C unless otherwise stated
