■ Specifications

● R03 series are small circular connectors with screw on system. They are subminiature in size and are suited

for a variety of electronic equipment.

● A wide variety of molded cable assemblies are available for your requirement.

● R27 series based on R03 series feature high density and miniaturization.

■ Configuration

Cable Assemblies

Plug / Normal Clamp Type

R03-PB5M

Flange Mount Receptacle

R03-RB5F

Jack / Normal Clamp Type

R03-JB5F

Plug / Screw Clamp Type

R03-P5M

Bulkhead Mount Receptacle

R03-R5F

Jack / Screw Clamp Type

R03-J5F

TAJIMI ELECTRONICS CO., LTD.

Series

R05

R27

Connections

Screw Coupling

Termination

Solder

Temperature and Humidity

-25º C to +85º C 85% Max.

Number of Pins

2, 3,5,6,8,12

8,12

Shell Material / Finish

Brass and Zinc Alloy / Nickel

Contact Material / Finish

Copper Alloy / Gold over Nickel

Corrosion Resistance

Salt Spray 5% 48H

Miniature Circular Connectors

B

Plug / Normal Clamp Type

Q

R

P

Plug / Screw Clamp Type

B

Jack / Normal Clamp Type

E

F

G

Bulkhead Mount Receptacle

4-øN

L

M

E

J

G

Flange Mount Receptacle

Series

Insert

size

No. of

Pins

Dimensions (mm)

A

B

C

D

E

F

G

H

J

K

L

M

N

P

Q

R

R03

62, 3,5

12.0 32.0

5.2 10.5 P=0.75

1.5 9.0 18.0 9.0 P=0.5

9.5 10.5 10.5 15.0 2.2 35.0 10.5

9.5

96, 8

15.5 34.0

6.2 M14 P=1

1.5 9.0 18.0 12.0 P=0.8

9.5 10.5 13.0 17.5 2.2 37.0 13.5 10.5

12

12

20.0 39.0 10.5 M18 P=1

1.5 9.0 18.0 M16 P=1

9.5 10.5 17.0 22.5 2.8 37.0 13.5 10.5

R27

68

12.0 32.0

5.2 10.5 P=0.75

1.5 9.0 18.0 9.0 P=0.5

9.5 10.5 10.5 15.0 2.2 35.0 10.5

9.5

912

15.5 34.0

6.2 M14 P=1

1.5 9.0 18.0 12.0 P=0.8

9.5 10.5 13.0 17.5 2.2 37.0 13.5 10.5

26

26

26

26

26
