EMC Components

MPZ Series MPZ2012 Type

Ferrite Beads

SMD

Size: JIS/IEC 2012, EIA 0805

FEATURES

• The MPZ series are multilayer chip impeders for power supply

line applications.

• High miniaturized, these parts nonetheless exhibit low DC

resistance and high current handling capability.

• The products contain no lead and also support lead-free

soldering.

APPLICATIONS

Noise elimination of DC power supply lines for USB interface

circuitry, personal computers, electronic games, hard disk drives,

and other general electronic equipment.

Also effective as a noise countermeasure in signal lines.

PRODUCT IDENTIFICATION

(1)Series name

(2)Dimensions L

×W

(3)Material code

(4)Nominal impedance

331: 330

Ω at 100MHz

(5)Characteristic type

(6)Packaging style

T: Taping

ELECTRICAL CHARACTERISTICS

CHARACTERISTICS(DERATING) about the rating current at 85°C or

more in temperature of the product.

SHAPES AND DIMENSIONS/RECOMMENDED PC BOARD

PATTERN

TEMPERATURE RANGES

PACKAGING STYLE AND QUANTITIES

RATED CURRENT vs. TEMEPERATURE CHARACTERISTICS

(DERATING)

Part No.

Impedance

(

Ω)[100MHz]

DC resistance

(

Ω)max.

(A)max.

min.

typ.

MPZ2012S300A

20

30

0.01

5

MPZ2012S101A

75

100

0.02

4

MPZ2012S221A

165

220

0.04

3

MPZ2012S331A

250

330

0.05

2.5

MPZ2012S601A

450

600

0.1

2

MPZ 2012 S 331 A

T

(1)

(2) (3) (4) (5) (6)

Operating/storage

–55 to +125°C

Packaging style

Quantity

Taping

4000 pieces/reel

0.5

±0.3

2+0.3, –0.1

Weight: 8mg

Dimensions in mm

1

1.3

1.3

0

1

2

3

4

5

6

–55 –35

–15

5

25

45

65

85

105

125

Temperature(˚C)

S300A

S331A

S101A

S221A

S601A
