Part Number System for Pan-Term ® Metric Terminals

Insulation

N = Nylon

NF = Nylon

Funnel

V = Vinyl

Wire Range

1 = 0.5 – 1.0mm

2

(22 – 18 AWG)

2 = 1.5 – 2.5mm

2

(16 – 14 AWG)

6 = 4.0 – 6.0mm

2

(12 – 10 AWG)

Stud Size

3 = M3 (#6)

4 = M4 (#8)

5 = M5 (#10)

6 = M6 (1/4)

8 = M8 (5/16)

R = Ring

F = Fork

B = Butted

Seam

Std. Pkg. Size

X= 10

E= 20

Q= 25

L= 50

C = 100

PM

V

1

B

C

Tongue Configuration

Special Configuration

R

3

Metric Ring Terminal, Nylon Insulated – Funnel Entry

• Ring tongue design assures a secure connection in high vibration

applications

• Metal insulation grip sleeve crimps to wire insulation, providing

protection to the crimp joint during high vibration applications

• Internal barrel serrations assure good wire contact and maximum

tensile strength

• Maximum insulation temperature 221°F (105°C)

• Rated up to 600 V

For crimping tool information, see pages D1.84 and D1.88.

Type PMNF-R

C

L

W

Type

PM = Pan-Term ®

Metric

Part Number

Wire

Range

(mm2)

Color

Code

Max.

Ins.

(mm)

Stud

Size

Figure Dimensions

(mm)

Recommended

Installation

Tool

Std.

Pkg.

Qty.

Std.

Ctn.

Qty.

L

W

C

PMNF1-3R-C

0.5 – 1.0

Red

3.76

M3

19.3

5.8

5.3

CT-1550,

CT-2500

100

500

PMNF1-4R-C

3.76

M4

21.6

7.9

6.4

100

500

PMNF1-5R-C

3.76

M5

21.8

8.9

6.4

100

500

PMNF1-6R-C

3.76

M6

26.7

10.9

9.7

100

500

PMNF2-3R-C

1.5 – 2.5

Blue

4.11

M3

19.4

5.9

4.8

CT-1550,

CT-2500

100

500

PMNF2-4R-C

4.11

M4

21.8

7.9

7.4

100

500

PMNF2-5R-C

4.11

M5

22.4

8.9

7.4

100

500

PMNF2-6R-L

4.11

M6

26.5

10.9

10.7

50

500

PMNF6-3R-L

4.0 – 6.0

Yellow

5.94

M3

26.7

5.8

9.1

CT-1550,

CT-2500

50

250

PMNF6-4R-L

5.94

M4

27.4

7.9

9.1

50

250

PMNF6-5R-L

5.94

M5

27.4

9.7

9.1

50

250

PMNF6-6R-L

5.94

M6

30.2

10.9

10.9

50

250

PMNF6-8R-L

5.94

M8

31.5

13.2

10.9

50

250
