40.3 Control Relays and Timers

EASY Intelligent Relays

EASY/MFD Power Supplies, Accessories and Software

Contents

Description

Page

EASY500/700/800 Intelligent Relays . . . . . . . . . . .

V7-T40-20

EASY/MFD Expansion Modules . . . . . . . . . . . . . .

V7-T40-25

MFD Intelligent Relays . . . . . . . . . . . . . . . . . . . . .

V7-T40-28

EASY/MFD Communication Modules . . . . . . . . . .

V7-T40-33

EASY/MFD Power Supplies, Accessories

and Software

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . .

V7-T40-37

Technical Data and Specifications . . . . . . . . . .

V7-T40-38

Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . .

V7-T40-38

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . .

V7-T40-39

EASY/MFD Power Supplies, Accessories and Software

Product Description

EASY/MFD Power Supplies

12 Vdc and 24 Vdc power

supplies for applications

where only 100–240 Vac

is available.

EASY/MFD Accessories

Memory modules, cables

and other components to

complete your automation

solutions.

EASYSoft Software

The EASYSoft software is

used to program all of the

EASY and MFD controllers

and displays. The Windows®-

based software provides

straightforward circuit

diagram input and editing

and the diagrams can be

displayed in the format

desired. When EASY800

and MFD controllers are

connected using EASY-NET,

all connected devices can

be accessed and their

programs loaded from a

single controller.

EASYSoft includes an

integrated offline simulation

tool that allows users to

test a circuit diagram

before commissioning.

Product Selection

EASY Power Supplies 1

Note

1 See Technical Data and Specifications on Page V7-T40-38 for more information.

Description

Catalog

Number

100–240 Vac input to 12 Vdc at 20 mA/24 Vdc at 250 mA

EASY200-POW

100–240 Vac input to 24 Vdc at 1.25A

EASY400-POW
