1 / 9 page  Rev Date: 3/3/2022 1 www.seielect.com This specification may be changed at any time without prior notice. marketing@seielect.com Please confirm technical specifications before you order and/or use. RSF / RSMF Series General Purpose Metal Oxide Resistor Stackpole Electronics, Inc. Resistive Product Solutions Features: • Lower-cost alternative to carbon comps and wirewounds • Coating meets UL 94V-0 • Meets solvent test of Mil Standard 202, Method 215 • Cut and formed product is available on select sizes - contact Stackpole • Higher or lower resistance values may be possible - contact Stackpole • Flameproof • 100% RoHS compliant and lead free without exemption • Halogen free • REACH compliant Electrical Specifications Mechanical Specifications Maximum Maximum Type/Code Working Overload Voltage (V) (1) Voltage (V) 1% 2% 5% RSF12 0.5 250 400 350 ± 200 0.1 - 150K 0.1 - 75K 0.1 - 510K RSF1 1 350 600 600 ± 200 0.1 - 510K RSF2 2 350 600 600 ± 200 0.1 - 510K RSF3 3 800 1000 750 ± 200 0.1 - 470K 0.1 - 510K 0.1 - 510K RSF5 5 1000 1000 750 ± 200 0.1 - 470K 0.1 - 510K 0.1 - 510K RSMF12 0.5 250 400 350 ± 200 0.1 - 46.4K 0.1 - 47K 0.1 - 470K RSMF1 1 350 600 500 ± 200 0.1 - 470K RSMF2 2 350 600 500 ± 200 0.1 - 470K RSMF3 3 500 800 600 ± 200 0.1 - 118K 0.1 - 120K 0.1 - 470K RSMF5 5 1000 1000 750 ± 200 0.1 - 470K 0.1 - 510K 0.1 - 510K Power Rating (W) @ 70ºC Dielectric Withstanding Voltage (V) Ohmic Range (2) (Ω) and Tolerance TCR (ppm/ºC) 0.1 - 100K (2) Contact Stackpole for resistance values outside the specified range 0.1 - 120K 0.1 - 75K 0.1 - 100K (1) Lesser of or maximum working voltage √ P*R 0.35 ± 0.04 0.13 ± 0.03 1.10 ± 0.12 0.03 ± 0.003 0.250 inches 9.00 ± 1.00 3.20 ± 0.80 28.00 ± 3.00 0.70 ± 0.08 6.35 mm 0.43 ± 0.06 0.18 ± 0.04 1.10 ± 0.20 0.03 ± 0.002 0.250 inches 11.00 ± 1.50 4.50 ± 1.00 28.00 ± 5.00 0.80 ± 0.05 6.35 mm 0.59 ± 0.06 0.22 ± 0.04 1.18 ± 0.20 0.03 ± 0.004 0.250 inches 15.00 ± 1.50 5.50 ± 1.00 30.00 ± 5.00 0.75 ± 0.10 6.35 mm 0.69 ± 0.04 0.24 ± 0.02 1.38 ± 0.12 0.03 ± 0.002 0.250 inches 17.50 ± 1.00 6.00 ± 0.50 35.00 ± 3.00 0.80 ± 0.05 6.35 mm 0.96 ± 0.04 0.31 ± 0.02 1.38 ± 0.12 0.03 ± 0.002 0.250 inches 24.50 ± 1.00 8.00 ± 0.50 35.00 ± 3.00 0.80 ± 0.05 6.35 mm 0.24 ± 0.03 0.09 ± 0.01 1.10 ± 0.12 0.02 ± 0.003 0.250 inches 6.00 ± 0.80 2.30 ± 0.30 28.00 ± 3.00 0.55 ± 0.07 6.35 mm 0.35 ± 0.04 0.13 ± 0.03 1.10 ± 0.12 0.03 ± 0.003 0.250 inches 9.00 ± 1.00 3.20 ± 0.80 28.00 ± 3.00 0.70 ± 0.08 6.35 mm 0.43 ± 0.06 0.18 ± 0.04 1.18 ± 0.20 0.03 ± 0.002 0.250 inches 11.00 ± 1.50 4.50 ± 1.00 30.00 ± 5.00 0.80 ± 0.05 6.35 mm 0.59 ± 0.06 0.22 ± 0.04 1.18 ± 0.20 0.03 ± 0.004 0.250 inches 15.00 ± 1.50 5.50 ± 1.00 30.00 ± 5.00 0.75 ± 0.10 6.35 mm 0.69 ± 0.04 0.24 ± 0.02 1.38 ± 0.08 0.03 ± 0.002 0.250 inches 17.50 ± 1.00 6.00 ± 0.50 35.00 ± 2.00 0.80 ± 0.05 6.35 mm Unit Body Length Body Diameter Lead Length (Bulk) Lead Diameter Lead-Tape Specification Type/Code A B C D RSMF5 RSF5 RSMF12 RSMF1 RSMF2 RSF12 RSF1 RSF2 RSF3 RSMF3 |
