Power & Energy Solution

Features

RoHS

COMPLIANT

2002/95/EC

Unit: mm

ECU-1050

NEW

ƒ

TI Cortex A8 600MHz CPU with DDR3L 256MB RAM

ƒ

Web service for remotely on-line monitoring

ƒ

Firmware update by SD card and online update

ƒ

Data logger on SD card

ƒ

Support dual SIM slots for communication redundant

ƒ

Support MQTT Client for cloud communication

ƒ

Wide Operating temperature: -40 ~ 70°C

Cloud enabled

Intelligent Communication Gateway

for IIOT application

Introduction

For facility monitoring, distributed solar power, smart factory sector, especially cloud based applications which require a total wireless and Ethernet communication solutions, Advantech

has released the ECU-1050TL RISC-based industrial communication gateway. ECU-1050TL has an open platform design with Cortex A8 processor, one 10/100 Ethernet ports and

operating temperature range of -40~70°C. With Linux operating system and open Edgelink SDK, which enable to system integrators to develop applications which precisely fit their need.

Specifications

General

ƒ

Certification

CE, FCC

ƒ

Mounting

Wall-Mount/ DIN-Rail

ƒ

Power consumption (typical) 2.4W @ 24VDC

ƒ

Power Requirements

10 ~ 30 VDC

System

ƒ

CPU

TI Cortex A8, 600MHz

ƒ

Memory

DDR3L 256MB

ƒ

Indicators

LEDs for Power, LAN (LINK, ACT),

Programmable

ƒ

Storage

512MB NAND Flash

ƒ

SD Slot

1 x Micro-SD slot

ƒ

Watchdog

Yes

ƒ

Real-time clock

Yes

Communication

ƒ

Ethernet Port

1 x 10/100 Base-T RJ-45 ports

ƒ

Wireless (Optional)

Interface: 2x Mini-PCIe (Full-size)

Type: WIFI/4G/Cellular

Signal: USB

ƒ

Communication Protocol

IEC-60870-5-104

Modbus TCP/RTU

MQTT

FTP/HTTP/DHCP/TCP/IP

ƒ

PLC Driver Support

100+ PLC drivers

ƒ

Data Logger

Real-time datalogger

ƒ

Database uplink

ODBC/ FTP

ƒ

Programming support

Linux C, Restful API, Web service API.

Event Manager

Software

ƒ

OS Support

RT-Linux 4.9

ƒ

Configuration Tool

Advantech Edgelink Studio

Environment

ƒ

Operating Temperature

-40~70°C

ƒ

Storage Temperature

-40~85°C

ƒ

Humidity

5 ~ 95% (non-condensing)

Ordering Information

ƒ

ECU-1050TL-R10AA

TI Cortex A8 industrial communication gateway with

Edgelink

Cellular Solution (SIM card is not included)

ƒ

96PD-EC25EFA

LTE Cat 4 Module with GNSS

ƒ

1750006264

SMA(F) Cable, 15 cm

ƒ

1750005865

Dipole Antenna, 11 cm

WIFI Solution (recommended)

ƒ

96PD-RYUW131

2.4GHz Wi-Fi Full/Half Size Mini PCIe Card

ƒ

1750006043

SMA(M) cable, 15 cm

ƒ

1750000318

2dBi antenna for testing, 11 cm

Storage Solution

ƒ

96FMMSDI-4G-ET-AT1 ATP 4G MICRO SD CARD I-GRD SLC(G)

ƒ

96FMMSDI-8G-ET-AT1 ATP 8G MICRO SD CARD I-GRD SLC(G)

Dimensions

All product specifications are subject to change without notice.

Last updated: 12-Oct-2021
