Industrial Motherboards & Systems

Features

RoHS

COMPLIANT

2002/95/EC

NEW

ƒ

Rockchip RK3399 ARM Dual Cortex-A72 and Quad Cortex-A53 1.8 GHz

ƒ

Onboard LPDDR4 2 GB

ƒ

HDMI 1920x1080 at 60Hz

ƒ

Dual Lan, 1 2-wire RS-232, 1 USB3.0, 1 USB2.0, 1 Micro SD

ƒ

1 mini-PCIe for LTE/WiFi/BT

ƒ

Compatible with UIO40-Express modules: UIO-4030, UIO-4032 and

UIO-4034

ƒ

Supports Linux and Android

ƒ

4 Kinds of Rear I/O for Each Vertical Focus: IEM, Self Service, Automation

and Networking

EPC-R3710

Rockchip RK3399 Cortex-A72

UIO40-Express Edge AI Box Computer

Introduction

EPC-R3710 is an Arm based Box Computer powered by a high-performance Rockchip RK3399 ARM dual Cortex-A72 and quad Cortex-A53 high performance processor which supports

4K display from HDMI. It offers both rich display as dual HDMI/LVDS/eDP and rich IO as dual GbE/2serials/3USB/12GPIO. EPC-R4710 also features Mini-PCIe slot for integrating

Wi-Fi, Bluetooth, and 3G/4G modules. It is an ideal solution for HMI, IoT gateway, healthcare application.

Specifications

Model

EPC-R3710NO-XAA100

EPC-R3710NO-XAA120

EPC-R3710NO-XAA140

EPC-R3710NO-XAA160

Processor System

CPU

Rockchip RK3399 ARM dual Cortex-A72 and quad Cortex-A53 1.8 GHz

Memory

Technology

LPDDR4

Capacity

2 GB On-board

Flash

16GB of eMMC NAND Flash for OS and Advantech's boot loader

Graphics

HDMI

1 HDMI 2.0, 1920 x 1080 at 60Hz

Graphics Engine

OpenGL ES 1.1/2.0/3.1, OpenCL 1.1, DirectX 11

H/W Video Codec

Decoder: MPEG-1, MPEG-2, MPEG-4, H.263, H.264, AVS, VC-1, VP8, MVC, HEVC/H.265 decoder, 4k@60FPS

Encoder: H.264 (BP@level4.0, MP, HP@level4.0), MVC and VP8

Ethernet

Chipset

RTL8211FSI

Speed

2 10/100/1000 Mbps

Watchdog Timer

Watchdog Timer

Yes

Front I/O

USB

1 x USB3.0 Type A, 1 x USB 2.0 Type A

GbE

2 x RJ45 for GbE

Rear I/O

1 x RS-485, 1 x 2 wires RS-232

4 x DIs, 4 x DOs

2 x 2 wires RS-232

1 x GbE, 2 x USB 2.0

2 x 2 wires RS-232

4 X GbE (Hub)

Expansion

Full-Size Mini PCIe

1 Full Size Mini PCIe Slot (with PCIE/USB)

M.2 Micro

-

SD Socket

1 Micro SD Socket

SIM

1 Nano SIM Slot

Antenna Holes

3

Power

Power Supply Voltage

+12V

Power Type

Lockable DC-Jack

Power Consumption

11.5W(burning)

Environment

Operating Temperature

0 ~ 50 °C/-20 ~ 70 °C

Operating Humidity

5% ~ 95% relative humidity, non-condensing

Mechanical

Dimensions

174 x 108 x 41 mm

Mounting

Wall mount

Weight

TBD

Operating System

Linux

Debian

Android

Android

Certifications

CCC/CE/FCC/BSMI Class B

All product specifications are subject to change without notice.

Last updated: 22-Apr-2022
