Dimensions

Unit: mm

Packing List

Part Number

Description

96966410000/10

NXP i.MX6D/Q 1GHz computing board

1960074545N001

Wall mount

EPC-R6410

Ordering Information

Part Number

CPU

Memory

eMMC SD

CAN UART

GPIO

VGA

HDMI

USB Host LAN Operating

Temperature

EPC-R6410CD-PAA1E

NXP i.MX6D

1GB

8GB

1

1

4

8

1

1

6

1

0 ~ 55 °C

EPC-R6410CQ-VAA1E

NXP i.MX6Q

2GB

8GB

1

1

4

8

1

1

6

1

0 ~ 55 °C

Front View

Rear View

Optional Accessories

Part Number

Description

96PSA-A36W12W7-5 ADP A/D 100-240V 36W 12V C6 LOCK DC JACK 62368

170203183C

Power cord 3P Europe (WS-010+WS-083) 183 cm

SQF-MSDM1-8G-21C SQF MICRO SD C10 MLC 8G (-25 ~ 85 °C)

1700008921

Power Cord 3P PSE 183cm

170203180A

Power cord 3P UK 2.5A/3A 250 V 1.83 M

1700019146

Power Cord CCC 3P 10A 250V 183cm

1700001524

Power cord 3P UL 10A 125 V 180 cm

968AD00018

Wifi BT module AW-NB136NF

1750002842

Wireless Antenna R-AN2450-5701RS R/P SM

1750007965-01

Antenna Cable R/P SMA (M) to MHF4, 300mm

968AD00479*

4G module LTE Cat 4 for China

EWM-C117FL06E*

LTE 4G,3G WCDMA/DC-HSPA+, 2G module, MPCI-L280H

1750006264

Antenna cable SMA(F)/MHF 15cm

1750008303-01

Antenna AN0727-64SP6BSM
