Embedded Single Board Computers

Features

ƒ

NVIDIA® JETSON™ TX2

Dual-Core NVIDIA Denver2 + Quad-Core ARM Cortex-A57

ƒ

NVIDAI Pascal™ 256 CUDA Cores GPU

ƒ

8GB LPDDR4 and 32GB eMMC NAND Flash Onboard

ƒ

1 Gigabit Ethernet Port and 2 PoE Ports (IEEE 802.3af)

ƒ

802.11a/b/g/n/ac 2×2 WiFi and Bluetooth 4.1

ƒ

AIM-Linux/Edge AI Software Package Support

ƒ

4K H.264/H.265 Encoder & Decoder

ƒ

-20 ~ 60 °C Operating Temperature/ 19V DC Power Supply

EPC-R7000

NVIDIA Jetson TX2 ARM-Based

Edge AI Inference Box Computer

Introduction

EPC-R7000 is an ARM-based Edge AI Inference Box Computer powered by NVIDIA® JETSON™ TX2 Dual-Core NVIDIA Denver2 + Quad-core ARM Cortex-A57 processor and NVIDIA

Pascal™ 256 CUDA cores GPU which provides high performance computing and supports the AIM-Linux/Edge AI Software Package. It is an ideal solution for AI and Machine Vision

applications.

Specifications

Form Factor

ARM-Based Box Computer

Processor

CPU

Dual-Core NVIDIA Denver 2 64-Bit CPU

Quad-Core ARM® Cortex®-A57 MPCore

GPU

NVIDIA Pascal™ GPU Architecture with 256 NVIDIA CUDA Cores

Memory

Technology

LPDDR4 1600MHz

Capacity

On-board 8GB LPDDR4

Flash

32GB eMMC NAND Flash

Graphics

HDMI

1 HDMI, 3840 x 2160 at 60Hz

H/W Video Codec

Encode: H.264, H265,VP8

Decode: H.264, H265,VP8, MPEG4, 4k@60FPS

Ethernet

Chipset

Integrated RGMII

Speed

1 10/100/1000 Mbps

RTC

Yes

WatchDog Timer

Yes

Expansion

SATA

(2.5" HDD/SSD 1TB, Optional)

Connectivity

WiFi

802.11a/b/g/n/ac 2×2 WiFi

Bluetooth

Bluetooth 4.1

I/O

USB

4 x USB 3.0 Type-A; 1 x USB 2.0 Micro-AB

Audio

1 x line-out

SPDIF

-

Serial Port

1 x 4-wire RS-232

CAN

-

GPIO

12 x GPIO (6 x DO, 6 x DI), 5V level

I2C

-

System Bus

-

Touch

-

I/R

-

LED

1 x Power LED

Button

1 x Reset Button, 1 x Recovery Button

Camera

2 x 802.3af (PSE Power Max 15.4W Out)

Power

Power Supply Voltage

19V

Power Type

DC-in

Power Consumption

TBD

Environment

Operational Temperature

-20 ~ 60 °C

Operating Humidity

5% ~ 95%

Mechanical

Dimensions (W x D)

204 x 138 x 67 mm

Operating System

Ubuntu

Certifications

CCC/CE/FCC Class B

RoHS

COMPLIANT

2002/95/EC

All product specifications are subject to change without notice.

Last updated: 7-Jul-2021
