RISC Computing Platforms

Features

ƒ

NXP ARM Cortex-A9 i.MX6 Dual/Quad 1GHz high performance processor

ƒ

On board DDR3 1066MHz 1GB/2GB memory and 8GB EMMC NAND flash

ƒ

Supports Dual Display: VGA/HDMI

ƒ

Supports 1 x mini-PCIe, 4 x serial ports, 6 x USB, 1 x M.2 socket,8 x GPIO,

1 x CAN

ƒ

Low power consumption, fanless design

ƒ

Supports Linux and Android BSP

EPC-R6410

NXP i.MX6 Cortex-A9 RISC Embedded

Mini-ITX Box Computer

Introduction

EPC-R6410 is the RISC based box computer which integrated NXP i.MX6D/Q Cortex-A9 1.0GHz high performance processor. It is designed for the applications that require high

performance and rich I/O but low power consumption. It supports dual display via HDMI and VGA up to 1080p, 1 Gigabit Ethernet, 6 USB 2.0 and 4 serials, as well as mini-PCIE for

4G/3G and M.2 for WiFi/BT. With wall mount brackets, fanless and dust-proof design, you can easy install in rugged environment.

Specifications

Form Factor

Embedded Box Computer

Processor System

CPU

NXP ARM Cortex-A9 i.MX6 Dual/Quad 1GHz processor

Capacity

1GB/2GB of onboard DDR3 at 1066 MHz

Flash

8 GB of eMMC NAND Flash for OS and 4 MB of SPI NOR Flash for ADV loader

Ethernet

Transceiver

RTL 8211

Speed

1 x 10/100/1000 Mbps

WatchDog Timer

C8051 (time out: 0.1~6553.5s, power on/off 4s)

I/O

USB

6 x USB2.0 host

Serial

4 (3 of RS-232 w/ 4wire,1 of RS-232/422/485 w/ 4wire)

CAN

1

GPIO

8

Button

1 x Reset button, 1 x Power button

Expansion

SD Socket

1 x SD slot

Mini-PCIe

1 (USB signal only)

M.2

1 (E-Key)

Power

Power Supply Voltage

12 V DC-in

Power Type

DC-Jack

Power Consumption

6W@Max Mode

Environment

Operational Temperature

0 ~ 55 °C

Operating Humidity

5 ~ 95% relative humidity, non-condensing

Mechanical

Dimensions (W x D x H)

200 x 230 x 50 mm

Operating System

Android

Android4.4.2@ Kernel V3.0.35/Android6.0@kernel V4.1.15

Linux

Yocto1.7, Kernel V3.14.28/Yocto2.1@Kernel V4.1.15

Certifications

CE/FCC/CCC Class B

RoHS

COMPLIANT

2002/95/EC

All product specifications are subject to change without notice.

Last updated: 7-Jul-2021
