www.advantech.com/products

Online Download

Ordering Information

Part Number

CPU

Memory

Flash

HDMI

LAN

USB

DI/DO

Serial Port

Micro SD

Nano

SIM

CAN

I/O Exp.

Operating

Temperature

EPC-R3720IQ-ALA200

EPC-R3720IQ-ALA10B (BSMI*)

Quad 1.6 GHz

6 GB

16 GB,

Yocto 3.0

1

2

2

4/4

1 RS-232,

1 RS-485

1

1

1

UIO-4030

-40 ~ 70 °C**

EPC-R3720IQ-ALA220

EPC-R3720IQ-ALA12B (BSMI*)

Quad 1.6 GHz

6 GB

16 GB,

Yocto 3.0

1

3

4

-

2 RS-232

1

1

1

UIO-4032

-40 ~ 70 °C**

EPC-R3720IQ-ALA240

EPC-R3720IQ-ALA14B (BSMI*)

Quad 1.6 GHz

6 GB

16 GB,

Yocto 3.0

1

2

2

-

2 RS-232

1

1

2 (CAN-FD on

front I/O, CANbus

on rear I/O)

UIO-4034

-40 ~ 70 °C**

EPC-R3720IQ-ALA260

EPC-R3720IQ-ALA16B (BSMI*)

Quad 1.6 GHz

6 GB

16 GB,

Yocto 3.0

1

6 (2 as independent,

and 4 by hub)

2

-

-

1

1

1

UIO-4036

-40 ~ 70 °C**

*BSMI SKU is for sale in Taiwan only

**BSMI SKU supports only -40~60°C

EPC-R3720

Packing List

Part Number

Description

EPC-R3700-DR01

Wall Mount BKT

Optional Accessories

Part Number

Description

96PSA-A36W12W7-5 ADP A/D 100-240V 36W 12V C6 LOCK DC JACK 62368

1700001524

Power Cord 3P UL 10A 125V 180cm

170203183C

Power Cord 3P Europe (WS-010+WS-083) 183cm

170203180A

Power Cord 3P UK 2.5A/3A 250V 1.83M

1700008921

Power Cord 3P PSE 183cm

1700019146

Power Cord CCC 3P 2.5A 250V 183cm

1700033212-01

Y Cable for CAN & RS-232 Debug

AIW-154BN

802.11ac+BT5.0 NXP 88W8997 M.2 2230 PCIe+UART

1750008717-01

Dipole Ant. D.B 2.4/5G WIFI 3dBi SMA/M-R BLK

1750007965-01

Antenna Cable R/P SMA (M) to MHF4, 300mm

AIW-344FQ-*01

AIW-3 series LTE CAT4 mini PCI-e module

1750008303-01

Antenna 4G/LTE Antenna L=13 cm

1750006009

Antenna Cable SMA (F) to MHF 1.32 25cm

*Please contact us for suggesting suitable cellular module for your region

Front I/O

Dimensions

Unit: mm

Lockable DC-Jack

2 GbE LANs

COM/CAN

2 USBs

HDMI

Grounding Screw
