RISC Computing Platforms

Features

ƒ

NVIDIA Jetson Module compatible Barebone PC

ƒ

Industrial and Expandable Design

ƒ

HDMI up to 3840 x 2160 at 60Hz resolution

ƒ

Dual GbE LAN, 2 USB3.2 Gen 1

ƒ

1 Micro SD Socket & 1 Nano SIM Slot

ƒ

1 M.2 3042 Key B Slot, 1 M.2 2230 Key E Slot

ƒ

4 Kinds of Rear I/O for Each Vertical Focus: IEM, Self Service, Automation

and Networking

ƒ

Qualified for Edge AI SRP of WISE-DeviceOn

EPC-R7200

Industrial-Grade Nvidia Jetson Barebone

Box PC

Specifications

Model

EPC-R7200IJ-ALA100

EPC-R7200IJ-ALA120

EPC-R7200IJ-ALA140

EPC-R7200IJ-ALA160

Compatible Modules

NVIDIA Jetson Series

Nano / TX2 NX / Xavier NX

Graphics

HDMI

1 x HDMI 2.0, Maximum Resolution 3840 x 2160 at 60Hz

Graphics Engine

NVIDIA Maxwell GPU / Pascal GPU / Volta GPU on Jeston Modules

H/W Video Codec

Up to 4K encode/decode

Ethernet

Chipset

NVIDIA Jetson integrated RGMII and Intel 1GbE Controller

Speed

2 10/100/1000 Mbps

Indicator

LED

1 x Power LED; 1 x programmable LED

Front I/O

USB

2 x USB3.2 Gen 1 Type A

GbE

2 x RJ45 for GbE

Rear I/O

1 x RS-485, 1 x 2 wires RS-232

4 x DIs, 4 x DOs

2 x 2 wires RS-232

1 x GbE, 2 x USB 2.0

2 x 2 wires RS-232

1 x CAN Bus 2.0B

4 X GbE (Hub)

Expansion

M.2

1 M.2 2230 Key E Slot (USB2.0/PCIe/UART/I2S)

1 M.2 3042 Key B Slot (USB3.0/I2C)

SD Socket

1 Micro SD Socket

SIM

1 Nano SIM Slot

Antenna Holes

4

Power

Power Supply Voltage

9-24V

Power Type

2-pole lockable DC-in

Power Consumption

5 ~ 15 W (Depends on Module Selection)

Environment

Operating Temperature

-20~60 / -20~70*

Operating Humidity

5% ~ 95% relative humidity, non-condensing

Mechanical

Dimensions

152 x 138 x 42 mm

Mounting

Wall mount, DIN Rail mount

Weight

925g

Operating System

Linux

Ubuntu

Certifications

CE/FCC Class B

* -20 ~ 70 supports by specific Power Mode of Jetson Modules

RoHS

COMPLIANT

2002/95/EC

NEW

All product specifications are subject to change without notice.

Last updated: 7-Sep-2022
