WL2000-R5300 | W2000

COMPACT PHOTOELECTRIC SENSORS

Dimensional drawing (Dimensions in mm (inch))

45 (1.77)

1

2

5

4

3

48.6 (1.91)

9.8

(0.39)

32.1 (1.26)

Internal thread

(1/2 - 14NPSM)

External thead

(M30 x 1.5)

5.7 x 7.8

slots

6

6

①  LED indicator green: Supply voltage active

②  Status indicator LED red: signal strength

③  Status indicator LED, yellow: Output active

④  Center of emitter optical axis

⑤  Center of receiver optical axis

⑥  Mounting hole ø 0.2 mm x 0.8 mm

Recommended accessories

Other models and accessories

www.sick.com/W2000

Brief description

Type

Part no.

Reflectors

Rectangular, screw connection, 47 mm x 47 mm, PMMA/ABS, Screw-on, 2 hole mount-

ing

P250

5304812

Rectangular, screw connection, 38 mm x 15 mm, PMMA/ABS, Screw-on, 2 hole mount-

ing

PL20A

1012719

Rectangular, screw connection, 56 mm x 28 mm, PMMA/ABS, Screw-on, 2 hole mount-

ing

PL30A

1002314

Rectangular, screw connection, 37 mm x 56 mm, PMMA/ABS, Screw-on, 2 hole mount-

ing

PL40A

1012720

Rectangular, screw connection, 80 mm x 80 mm, PMMA/ABS, Screw-on, 2 hole mount-

ing

PL80A

1003865

Self-adhesive

REF-IRF-56

5314244

Round, screw connection, PMMA/ABS, Center hole mounting, screw-on

C110A

5304549

2019-01-28 13:26:15 | Online data sheet

Subject to change without notice

PHOTOELECTRIC SENSORS | SICK

5
