RISC Computing Platforms

Features

ROM-3310

TI Sitara™ ARM® AM3352 Cortex®-A8

1GHz RTX2.0 Module

ƒ

TI Sitara™ ARM® AM3352 Cortex®-A8 1Ghz high performance processor

ƒ

On board DDR3 512MB memory / 4GB EMMC

ƒ

Supports wide range power input 5V~24V

ƒ

Supports 1 GbE, 1 USB 2.0, 1 USB 2.0 OTG, 2 CANbus, 10 GPIO, 4 UART,

1 I2C, 1 I2S, 1 SPI, 1 SDIO

ƒ

Operating temperature 0 ~ 60 °C / -40 ~ 85 °C

ƒ

Low power consumption, fanless design

ƒ

Supports Linux BSP

Introduction

ROM-3310 RTX2.0 module integrates an ARM Cortex A8 single core 1 GHz TI AM3352 series ultra low power SoC and I/O solution with Linux. TI AM3352 supports multiple serial

ports, 5V~24V wide range power inputs, and wide temperature -40 ~ 85 °C operation for data collection in industrial applications. Based on a thickness of 2 mm board, it uses an

anti-oxidization golden finger design.

ROM-3310 RTX2.0 module offers an Advantech ROM-DB3900 evaluation carrier board for easy integration and hardware design reference, and also provides a Linux BSP utility and

reference codes for application development and device integration.

Specifications

Form Factor

RTX 2.0

Processor System

CPU

TI Sitara Cortex A8 AM3352 1Ghz

Memory

Technology

DDR3 on board 800MHz

Capacity

512MB

Flash

4GB EMMC NAND Flash for O.S & 4MB SPI NOR Flash for ADV loader

Graphics

Parallel RGB

1 x 24-bit TTL, 1366 x 768

Ethernet

Chipset

TI AM3352 Integrated RGMII

Speed

1 x 10/100/1000 Mbps

RTC

RTC

Yes

WatchDog Timer

MSP430G2202 (time out : 0.1~6553.5s, power on/off 4s)

I/O

USB

1 x USB 2.0 host,1 x USB 2.0 OTG

I2S

1

SDIO

1

Serial Port

4 x UART (1 x 4 wire, 3 x 2 wire w/ 3.3V)

SPI

1

CAN

2 x CAN 2.0

GPIO

10

I2C

1

Power

Power Supply Voltage

5 ~ 24 V

Power Consumption

2.11W (Max)

Environment

Operating Temperature

0 ~ 60 °C/ -40 ~ 85 °C

Operating Humidity

0% ~ 90% relative humidity, non-condensing

Mechanical

Dimensions (W x D)

68 x 68 mm

Operating System

Linux Kernel v3.2.0

Certifications

CE/FCC Class B

RoHS

COMPLIANT

2002/95/EC

All product specifications are subject to change without notice.

Last updated: 7-Jul-2021
