74HC393D

6

13.3. DC Characteristics (Note) (Unless otherwise specified, Ta = -40 to 125 �)

Characteristics

High-level input voltage

Low-level input voltage

High-level output voltage

Low-level output voltage

Input leakage current

Quiescent supply current

Symbol

VIH

VIL

VOH

VOL

IIN

ICC

Test Condition

�

�

VIN = VIH or VIL

VIN = VIH or VIL

VIN = VCC or GND

VIN = VCC or GND

IOH = -20 µA

IOH = -4 mA

IOH = -5.2 mA

IOL = 20 µA

IOL = 4 mA

IOL = 5.2 mA

VCC (V)

2.0

4.5

6.0

2.0

4.5

6.0

2.0

4.5

6.0

4.5

6.0

2.0

4.5

6.0

4.5

6.0

6.0

6.0

Min

1.50

3.15

4.20

�

�

�

1.9

4.4

5.9

3.7

5.2

�

�

�

�

�

�

�

Max

�

�

�

0.50

1.35

1.80

�

�

�

�

�

0.1

0.1

0.1

0.4

0.4

±1.0

80.0

Unit

V

V

V

V

µA

µA

Note:

Operating Range spec of Topr = -40 � to 125 � is applicable only for the products which manufactured after

July 2020.
