TOAD347-RXB/TOAD347-RXC Series

ABSOLUTE MAXIMUM RATINGS (Tc = 25 ˚C)

DIMENSIONAL

Symbol

Item

Rating

Unit

Storage temperature

Tstg

−40 to +85

˚C

Operating case temperature

Tc

−40 to +85

˚C

APD forward current

If

1

mA

APD reverse current

Ir

500

µA

Positive supply voltage

Vdd

0 to +6

V

Soldering temperature / time

Tsol / tsol

260 / 5

˚C / s

Notes:

(2) Pf =

−30 dBm, M = 12

(3) DATA OUT (+), Light ON = Vout Logic HIGH

DATA OUT (

−), Light ON = Vout Logic LOW

(4)

λ = 1.3/1.55 µm

(5)

−10 dBm > Pf > −30 dBm

(6) 0.13 GHz < F < 1.75 GHz

(7) 1.75 GHz < F < 2.5 GHz

(8) 3 k

Ω (typ.) available

Item

Min

Typ.

Max

Unit

Note

ELECTRICAL AND OPTICAL CHARACTERISTICS (Tc = –40 to +85 ˚C, Vdd = +3.3 V to +5 V)

Positive supply current

—

50

—

mA

Breakdown voltage (Id = 10

µA, Tc = 25˚C)

35

—

85

V

Dark current (M = 12, Tc = 25˚C)

—

40

100

nA

Sensitivity

—

−33

—

dBm

(1)

Overload

—

−8

—

dBm

(1)

Bandwidth (

−3 dB)

1.4

2.0

—

GHz

(2)

Logic sense

(3)

Skew, DATA OUT (+) to DATA OUT (

−)

−20

—

20

ps

Optical return loss

—

—

−27

dB

(4)

Output signal amplitude

15

—

500

mVpp

(5)

Electrical return loss

10

—

—

dB

(6)

9

—

—

dB

(7)

Thermistor resistance (TOAD347-RXC, Tc = 25˚C)

9.5

10.0

10.5

k

Ω

(8)

Pin Assignme

1

2

3

4

Vapd

GND

DATA OUT

GND

Pin

Fun

PRECAUTION

(a) Power supply

A surge-free

To avoid cau

before turnin

(b) The product
