Specifications are subject to change without notice.

How to Order

Series

RX = Radial Leaded Component

Hold Current, Ihold

110-375 (1.10 Amps - 3.75 Amps)

Packaging Options

-

= Bulk Packaging

- 2 = Tape and Reel*

- AP = Ammo-Pak*

*Packaged per EIA 486-B

MF-RX SERIES, REV. G, 08/01

A

E

B

D

C

Product Dimensions

Packaging options:

BULK: All models = 500 pcs. per bag.

TAPE & REEL: MF-RX110 – MF-RX160 = 1500 pcs. per reel; MF-RX185 – MF-RX375 = 1000 pcs. per reel

AMMO-PACK: MF-RX110 – MF-RX160 = 1000 pcs. per reel; MF-RX185 – MF-RX375 = 500 pcs. per reel

Additional Features

A

B

C

D

E

Physical Characteristics

Model

Max.

Max.

Nom.

Tol. ±

Min.

Max.

Style

Lead Dia.

Material

MF-RX110

13.0

18.0

5.1

0.7

7.6

3.1

1

0.81

Sn/Cu

(0.512)

(0.709)

(0.201)

(0.028)

(0.299)

(0.122)

(0.032)

MF-RX135

14.5

19.6

5.1

0.7

7.6

3.1

1

0.81

Sn/Cu

(0.571)

(0.772)

(0.201)

(0.028)

(0.299)

(0.122)

(0.032)

MF-RX160

16.3

21.3

5.1

0.7

7.6

3.1

1

0.81

Sn/Cu

(0.642)

(0.839)

(0.201)

(0.028)

(0.299)

(0.122)

(0.032)

MF-RX185

17.8

22.9

5.1

0.7

7.6

3.1

1

0.81

Sn/Cu

(0.701)

(0.902)

(0.201)

(0.028)

(0.299)

(0.122)

(0.032)

MF-RX250

21.3

26.4

10.2

0.7

7.6

3.1

1

0.81

Sn/Cu

(0.839)

(1.039)

(0.402)

(0.028)

(0.299)

(0.122)

(0.032)

MF-RX300

24.9

30.0

10.2

0.7

7.6

3.1

1

0.81

Sn/Cu

(0.980)

(1.181)

(0.402)

(0.028)

(0.299)

(0.122)

(0.032)

MF-RX375

28.4

33.5

10.2

0.7

7.6

3.1

1

0.81

Sn/Cu

(1.118)

(1.319)

(0.402)

(0.028)

(0.299)

(0.122)

(0.032)

Typical Part Marking

Represents total content. Layout may vary.

RX110

0180T

MANUFACTURER'S

TRADEMARK

PART

IDENTIFICATION

LOT NO.

(T = TAIWAN

S = CHINA)

DATE CODE

(FIRST DIGIT =

LAST DIGIT OF YEAR;

NEXT THREE DIGITS =

DAY OF YEAR)

NOTE: Kinked lead option is available for

board standoff. Contact factory for

details.

Typical Time to Trip at 23˚C

0.01

0.001

110

100

0.1

1

10

100

1000

Fault Current (Amps)

MM

(INCHES)

DIMENSIONS =

0.81 (20AWG)
