How to Order

MF - RX 110 - 0 - 99

Product Designator

Series

RX = Radial Leaded Component

Hold Current, Ihold

110-375 (1.10 Amps - 3.75 Amps)

Packaging Options

- __ = Bulk Packaging without part number

suffix option

- 0-99 = Bulk Packaging with part number

suffix option

- 2 = Tape and Reel without part number

suffix option*

- 2-99 = Tape and Reel with part number

suffix option

- AP = Ammo-Pak*

- 0-14 = Kinked leads where straight leads are

standard

- 0-17 = Straight leads where kinked leads are

standard

Part Number Suffix Option

- 99 = As of date code April 1, 2005 all MF-RX

models are RoHS compliant. The suffix “-99”

can be used if a new part number is required

to reference the RoHS compliance.

Examples:

MF-RX110 ..........................................Bulk packaging

MF-RX110-0-99 ....Bulk packaging with part

number suffix option

MF-RX110-2 ..........Tape and reel packaging

MF-RX110-2-99 ....Tape and reel packaging

with part number suffix

option

*Packaged per EIA486-B

MF-RX SERIES, REV. L, 02/06

A

E

B

D

C

Product Dimensions

Packaging options:

BULK: All models = 500 pcs. per bag.

TAPE & REEL: MF-RX110 – MF-RX160 = 1500 pcs. per reel; MF-RX185 – MF-RX375 = 1000 pcs. per reel

AMMO-PACK: MF-RX110 – MF-RX160 = 1000 pcs. per reel; MF-RX185 – MF-RX375 = 500 pcs. per reel

A

B

C

D

E

Physical Characteristics

Model

Max.

Max.

Nom.

Tol. ±

Min.

Max.

Style

Lead Dia.

Material

MF-RX110

13.0

18.0

5.1

0.7

7.6

3.1

1

0.81

Sn/Cu

(0.512)

(0.709)

(0.201)

(0.028)

(0.299)

(0.122)

(0.032)

MF-RX135

14.5

19.6

5.1

0.7

7.6

3.1

1

0.81

Sn/Cu

(0.571)

(0.772)

(0.201)

(0.028)

(0.299)

(0.122)

(0.032)

MF-RX160

16.3

21.3

5.1

0.7

7.6

3.1

1

0.81

Sn/Cu

(0.642)

(0.839)

(0.201)

(0.028)

(0.299)

(0.122)

(0.032)

MF-RX185

17.8

22.9

5.1

0.7

7.6

3.1

1

0.81

Sn/Cu

(0.701)

(0.902)

(0.201)

(0.028)

(0.299)

(0.122)

(0.032)

MF-RX250

21.3

26.4

10.2

0.7

7.6

3.1

1

0.81

Sn/Cu

(0.839)

(1.039)

(0.402)

(0.028)

(0.299)

(0.122)

(0.032)

MF-RX300

24.9

30.0

10.2

0.7

7.6

3.1

1

0.81

Sn/Cu

(0.980)

(1.181)

(0.402)

(0.028)

(0.299)

(0.122)

(0.032)

MF-RX375

28.4

33.5

10.2

0.7

7.6

3.1

1

0.81

Sn/Cu

(1.118)

(1.319)

(0.402)

(0.028)

(0.299)

(0.122)

(0.032)

Typical Part Marking

Represents total content. Layout may vary.

RX110

0180T

MANUFACTURER'S

TRADEMARK

PART

IDENTIFICATION

LOT NO.

(T = TAIWAN

S = CHINA)

DATE CODE

(FIRST DIGIT =

LAST DIGIT OF YEAR;

NEXT THREE DIGITS =

DAY OF YEAR)

NOTE: Kinked lead option is available for

board standoff. Contact factory for

details.

Typical Time to Trip at 23 ßC

0.01

0.001

1

10

100

0.1

1

10

100

1000

Fault Current (Amps)

MM

(INCHES)

DIMENSIONS =

0.81 (20AWG)

Additional Features

■

Bulk packaging, tape and reel and Ammo-

Pak available on most models

■

Resettable circuit protection

■

Patents pending

Applications

Almost anywhere there is a low voltage

power supply, up to 60 V and a load to be

protected, including:

■

Security and fire alarm systems

■

Loud speakers

■

Power transformers
