ICS-R372

Fanless Rolling Stock Computer with

Intel® Atom™ x7-E3950 Processor

Preliminary Specifications

• Intel® Atom™ x7-E3950 Processor

• Certified with EN50155, EN50121, EN50125 and EN45545

• Vehicle/Rail Computer with 6x M12 GbE ports

• 2x M.2 Slots with up to 4x SIM card readers

• Wide range operating temperature from -40 to 70°C

• 2x HDMI and 4x USB ports

• 1x Internal HDD/SSD drive bay

• Support 24~36V or 72~110V power input

Processor System

CPU

Atom™ x7-E3950

Frequency

1.6 GHz

Core Number

Quad-core

BIOS

AMI SPI Flash BIOS

Chipset

SoC

Processor Graphics

Intel integrated HD Graphics 505

Fanless

Yes

Memory

Technology

LPDDR4 up to 2400 MHz

Max. Capacity

Up to 8GB (Factory default: 8GB)

Ethernet

Controller

Intel i210IT x6

Speed

10/100/1000 Mbps

Interface

M12 X-coded GbE x6

Storage

Type

SATA

Installation

Internal 2.5” drive bay x1 (HDD/SSD is not included)

Type

mSATA

Installation

mSATA socket x1 (default 128 GB)

I/O

Display

HDMI x2

GPS

u-blox NEO-M8N; 3 GNSS (GPS, Galileo, GLONASS,

BeiDou), default @ GPS + GLONASS dual band

G-sensor

ADXL 345

USB

USB 2.0 Type A x4

Antenna

SMA antenna hole x5 (includes GPS+GLONASS x1)

Expansion

M.2

2x M.2 3042 B Key

Cooling

Processor

passive CPU heatsink

System

fanless design with corrugated aluminum

Environment

Operating Temperature

-40~70°C / -40~158°F

Storage Temperature

-40~85°C / -40~185°F

Relative Humidity

5%~95% @ 40°C / 104°F (Storage Level)

Miscellaneous

Hardware Monitoring

Yes

Internal RTC with Li Battery

Yes

Mechanical

Dimension (W x H x D)

272.4 x 88.3 x 228 mm (10.72” x 3.48” x 8.97”)

Weight

5 kg

Mounting

Wall mount kit

Power

Connector

M12 K-coded (Ground, DC_IN, Ground, IGN, Chassis

Ground)

Input

SKU A: Input Rated: 24~36Vdc,

SKU B: Input Rated: 72~110Vdc

Driver Support

Microsoft Windows

Win 10 IoT

Linux

Linux: Redhat Enterprise 5, Fedora 14. Linux Kernel

2.6.18 or later

Certification

EMC

E13, CE Class A, FCC Class A, RoHS

Certified

MIL-STD-810G, EN50155, EN50121-3-2, EN50121-4,

EN50125, EN 45545

Features
