AD8665/AD8666/AD8668
Rev. A | Page 8 of 16
TIME (0.5µs/DIV)
VDD = 16V
RL = 10kΩ
CL = 10pF
AV = +1
TIME (5µs/DIV)
0V
8V
–100mV
0V
VIN
VOUT
VDD = ±8V
AV = –100
Figure 19. Small-Signal Transient Response
Figure 22. Positive Overload Recovery Time
TIME (2µs/DIV)
VDD =±8V
RL = 10kΩ
CL = 10pF
AV = +1
10
–10
–8
–6
–4
–2
2
4
6
8
0
TIME (5µs/DIV)
–8V
0V
0V
100mV
VIN
VOUT
VDD = ±8V
AV = –100
Figure 23. Negative Overload Recovery Time
Figure 20. Large-Signal Transient Response
80
0
–3
3
INPUT OFFSET VOLTAGE (mV)
70
60
50
40
30
20
10
–2
–1
0
1
2
VDD = 5V
VCM = 2.5V
TA = 25°C
550 AMPLIFIERS
70
0
1
1000
LOAD CAPACITANCE (pF)
10
100
60
50
40
30
20
10
VDD = 16V
VIN = 100mV p-p
+OS
–OS
Figure 24. Input Offset Voltage Distribution
Figure 21. Small-Signal Overshoot vs. Load Capacitance
