M–25

Dimensions are shown: Inch (mm)

Specifications and dimensions subject to change

www.ittcannon.com

M

TERMINATIONS

LOCK TYPE

BRASS CONTROL KEY

(Removes lock core)

Control key available separately,

part number: 11630CKBYST

.136 DIA.

(3,45)

S

N

5

6

3

6

5

o

.655

(16,62)

.225

(5,72)

.100

(2,54)

.034

(0,86)

.468

(11,88)

.965

(24,51)

.688

(17,46)

1.000

(25,40)

.500

(12,70)

.470

(11,94)

.105

(2,67)

1.047

(26,59)

Control Key

Lock Core

Plastic Facing

Lock

Switch

L

LATCH PAWL AND NUT

M

LATCH PAWL AND CLIP

N

WITH NUT

D

WITH CLIP

WC

WIRE LEAD

03

SOLDER LUG WITH HOLE

C

4 TUMBLER LOCK WITH DETENT

.085-.105 (2,16-2,67)

WITH CLIP

D, M

.085-.105 (2,16-2,67)

WITH NUT

N, L

PANEL THICKNESS

MOUNTING

STYLE

OPTION

CODE

2

BLACK

LOCK COLOR

OPTION

CODE

Lock Core Removal Instructions

To remove lock core, insert round-headed control key and pull.

Lock must be in position 2 (90º indexing), position 3 (45º indexing).

This feature permits changing key codes.

Black wire standard. other colors and lengths available,

consult Customer Service Center. UL style 1015.

Nut part number: 175050700

Clip part number: 906B00000

C&K BY Series

4 Tumbler Value Added Security Switchlocks

LOCK TYPE
