HORNET PRO

DS-HORNETPRO-3

Link Pins

LK1

LK2

Link Positions

Relay Outputs

LK1

LK2

RLY 1

RLY 2

Open

Open

Mom

Mom

Closed

Open

Mom

Latch

Open

Closed

Flipflop

Flipflop

Closed

Closed

Latch

Latch

230Vac Receiver

Place Link Cap Vertically

Advanced Operation

Configuring receivers

The link pins LK1 and LK2 set the action of the relays

1

/2 sec Mom = Relay will operate for 1/2 sec

Mom

= Relay will operate for as long as transmitter switch operated

Latch

= Relay will toggle ON/OFF on each transmitter button press

FlipFlop

= Relays 1 & 2 and 3 & 4 operate in pairs.

When button 1 is pressed relay 1 switches on, Relay 2 Switches off

When button 2 is pressed relay 2 switches on, Relay 1 Switches off

Relay 3 & 4 operate in the same manor to Transmitter buttons 3 & 4.

Note When using Keyfobs with “ON” “OFF” set the jumper links to MOM, then the receiver

output will energise when ON is pressed and relax when OFF is pressed

Link Positions

Switch relays

LK1

LK2

RLY 1

RLY 2

RLY 3

RLY 4

Open

Open

1

/2 sec

Mom

1

/2 sec

Mom

1

/2 sec

Mom

1

/2 sec

Mom

Closed

Open

Mom

Mom

Latch

Latch

Open

Closed

Mom

Mom

Mom

Mom

Closed

Closed

Latch

Latch

Latch

Latch

Link Pins

LED s

RF Receive

RF Transmit

LEARN

1

2

3

4

12-30V Version
