ORDERING INFORMATION

SDO2

60

O

External AC-link serial data output. Select external codec by enabling Canyon3D_Base+38h [5].

GPIO11

I/O

General-purpose input/output.

PCGNT

61

I

PC/PCI grant input. Enable PC/PCI by setting PCI 50h [10:8].

GPIO12

I/O

General-purpose input/output.

LINE_OUT_R-L

62

O

Line output: surround, left channel.

LINE_OUT_R-R

63

O

Line output: surround, right channel.

PC_BEEP

64

I

PC speaker input.

PHONE

65

I

Mono input.

CD_L

66

I

CD-audio input: left channel.

CD_GND

67

I

CD-audio input: ground.

CD_R

68

I

CD-audio input: right channel.

MIC

69

I

Microphone input.

LINE_IN_L

70

I

Line input: left channel.

LINE_IN_R

71

I

Line input: right channel.

AVDD[2:1]

72:83

I

Analog supply voltage, 5V.

AVSS[2:1]

73:82

I

Analog ground.

VREF

74

O

Reference voltage.

AFILT[2:1]

75:76

O

Antialiasing filter cap for the ADC channel.

CAP[2:1]

77:78

O

ADC and DAC reference caps.

LINE_OUT_L

79

O

Line output: front, left channel.

LINE_OUT_R

80

O

Line output: front, right channel.

MONO_OUT

81

O

Mono output.

RXD

84

I

MIDI receive data input. Enable MIDI I/O (MPU-401 I/O) by setting PCI 40h [3].

TXD

85

O

MIDI transmit data output. Enable MIDI I/O (MPU-401 I/O) by setting PCI 40h [3].

RST#

86

I

PCI reset input.

INT#

87

O

Interrupt request output.

PCICLK

88

I

PCI bus clock input.

GNT#

91

I

Bus master grant input.

REQ#

92

O

Bus master request output.

Table 1

ES1990 Canyon3D-2LE Pin Descriptions (Continued)

Names

Pin Numbers

I/O

Descriptions

Part Number

Description

Package

ES1990S

PCI Audio Accelerator

100-pin LQFP
