MITSUMI

1000mA Regulator MM166

F

1000mA Regulator

Monolithic IC MM166

F

Outline

This IC is a small, stable power supply with output voltage precision of ±2% (when IO = 500mA), maximum

output current of 1000mA, and I/O voltage difference of 0.2V typ. at 500mA.

Output noise reduction and output ON/OFF control pins are provided, making it ideal for portable equipment.

(HSOP-8)

Features

1. No-load current consumption

2.5mA typ.

2. I/O voltage difference

0.2V typ. (IO=500mA)

3. Ripple rejection rate

65dB typ. (f=120Hz, VRIPPLE=1VP-P, IO=250mA)

4. Output current

1000mA max.

5. Output noise voltage

45µVrms typ. (Cn=470pF)

6. Output voltage rank

1.5 ~ 5.0V (0.1V steps)

7. Output ON/OFF control

High

ON, Low

OFF

Package

HSOP-8, TO-252

Applications

1. Cordless telephone

2. Portable equipment, etc.

3. DVD

14

3

2

85

6

7

HSOP-8

1

VOUT

2

NC

3

GND

4

Cn

5

CONT

6

NC

7

NC

8

VIN

Pin Assignment

VIN

VO

GND

TO-252
