E L E C T R O N I C S I N C .

Surface Mount Power Inductor

TEL: (818) 892-0761

FAX: (818) 894-5791

http://www.pca.com

PCA ELECTRONICS, INC.

16799 SCHOENBORN ST.

NORTH HILLS, CA 91343

• Low loss material ensures operation in high frequency

switching converters, such as Buck, Boost or as output

averaging filter inductor

• Also suitable for use in high quality filter applications

• 500 KHz Switching Frequency

EPI BH30 Series

Product performance is limited to specified parameters. Data is subject to change without prior notice.

Package BH30

Electrical Parameters @ 25° C

Unless Otherwise Specified Dimensions are in Inches /mm ± .010 /.25

5.0

12.6

35.2

167

Inductance

(µH ± 15%)

@ 0 Adc

DCR

(

Ω Typ.)

.0148

.0377

.123

.333

Idc

(Amps)

4.8

2.8

1.40

.94

Part

Number

EPI3L8482BH30

EPI9L6282BH30

EPI290142BH30

EPI111941BH30

Inductance

(µH ± 15%)

@ Idc

3.8

9.6

116

(V-µsec)

@ 500 KHz

1.6

2.6

4.3

9.4

Temp. Rise

@ Idc

(°C Typ.)

.425

(10.80)

.360

(9.14)

.430

(10.92)

.360

(9.14)

.400

(10.16)

.060 (1.52)

Suggested

Pad

Latout

PCA

EPIXXXXXXBH30

D.C.

.360

Max.

(9.14)

Note: Coplanarity within .005” Max.

CSIXXXXXXBH30

Rev. 1

12/17/02

• Core Loss @ Vt : 15 mW •
