PLCC4 SMD Top View Package LED

SMTL4-RGY, RED/GREEN/YELLOW

Bivar reserves the right to make changes at any time without notice.

Bivar, Inc. — 4 Thomas, Irvine, California 92618, U.S.A.

Phone: (949) 951-8808 Fax: (949) 951-3974 Web: www.bivar.com

Revision A

02/16

Page 2 of 5

Radiation Diagram

Directivity Radiation

TA = 25°C unless otherwise noted

Electrical Characteristics

TA = 25°C & IF = 20 mA unless otherwise noted

Emitting

Color

Forward

Voltage (V)1

Recommend

Forward

Current (mA)

Reverse

Current (µA)

VR=5V

Dominant

Wavelength (nm)2

Luminous

Intensity (mcd)3

Viewing

Angle

2 Ө ½ (deg)

TYP

MAX

TYP

MAX

TYP

MIN

TYP

TYP

Red

1.85

2.3

20

10

640

18

36

Green

1.9

2.4

20

10

570

20

40

Yellow

1.9

2.4

20

10

585

10

16

120

1. Tolerance of Forward Voltage : ±0.05V.

2. Tolerance of Dominant Wavelength : ±0.1nm.

3. Tolerance of Luminous Intensity : ±15%.

Notes:

1. 10% Duty Cycle, Pulse Width ≤ 0.1 msec.

2. Solder time less than 5 seconds at temperature extreme.

Notes:

Absolute Maximum Ratings

TA = 25°C unless otherwise noted

Power Dissipation

72 mW

Continuous Forward Current

30 mA

Peak Forward Current 1

100 mA

Reverse Voltage

5 V

Derating Linear From 25°C

0.4 mA/°C

Operating Temperature Range

-40 ~ +85°C

Storage Temperature Range

-40 ~ +100°C

Soldering Temperature2

260°C

Electrostatic Discharge Classification (HBM)

2000 V
