PRODUCT

RPC

Room Pressure Monitor/Transmitter

PRESSURE RANGES

1

2

±1”WC, ±0.5”WC, ±250 Pa, ±125 Pa

±0.25”WC, ±0.125”WC, ±60 Pa, ±30 Pa

COMMUNICATIONS

-

BAC

None (Leave Blank)

BACnet® Communications

OPTIONS

AC

SP

OP

Continental pick-up port

Stainless plate pick-up port

Outside pick-up port

ORDERING

RPC

PART NUMBER

NOTE: Greystone Energy Systems, Inc. reserves the right to make design modifications without prior notice.

ANALOG MODEL

TERMINAL

FUNCTION

PWR

24 Vac/Vdc

COM

Common

OUT

Analog Output

RELAY

Digital Output

RELAY

Digital Output

BACnet® MODEL

TERMINAL

FUNCTION

PWR

24 Vac/Vdc

COM

Common

B +

B +

A -

A -

SHIELD

Shield

RELAY

Digital Output

RELAY

Digital Output

WIRING INFORMATION

0001301

Rev. 1

MENU

DOWN

UP

ZERO

HIGH PORT

LOW PORT

B+

A-

SHIELD

POWER

COMMON

BUZZER -

BUZZER +

RELAY

“WC

0.025

0001301

Rev. 1

MENU

DOWN

mA

Vdc

OUTPUT

UP

ZERO

HIGH PORT

LOW PORT

POWER

COMMON

BUZZER -

BUZZER +

RELAY

“WC

0.025
