Hand Tool Assembly
PV® Hand Tool
P/N : 10162308-001, 10162309-001 & 10162310-001
NOTE
Amphenol CS recommends using the hand tool for prototyping and small
production quantities only.
Open the handles and
insert the tool head into
the open holes.
The laser marking of
both
parts
should
match.
Unlock 2 pins by pushing
towards them.
Extract the pins.
Lock the pins by pushing
toward them. Hand Tool
is ready to use.
1
2
3
4
1
2
1
2
1
2
Tool Head
