CC1010-RTY1 数据表(PDF) 136 Page - Texas Instruments |
|
|
|
|||||||||||||||||||||||||||||
CC1010-RTY1 数据表(HTML) 136 Page - Texas Instruments |
|
|
136 / 152 page  CC1010 SWRS047 Page 136 of 152 Symbol Dimensions (mm) Remarks A 1.20 max Overall height A1 0.05 - 0.15 Standoff A2 1.00 ± 0.05 Package thickness D 12.00 ± 0.20 Terminal dimension D1 9.95 ± 0.10 Top package width D3 10.00 ± 0.10 Bottom package width E 12.00 ± 0.20 Terminal dimension E1 9.95 ± 0.10 Top package length E3 10.00 ± 0.10 Bottom package length R1 0.08 Min First radius R2 0.15 Ref. Second radius β 0 ° - 7° Foot angle β1 0 ° Min Shoulder angle β2 12 ° Top draft angle β3 12 ° Bottom draft angle C 0.09 - 0.20 Lead thickness L 0.60 ± 0.15 Foot length L1 1.0 Ref Lead length S 0.20 Min. - Ccc 0.080 Max Coplanarity Ddd 0.080 Max Bent lead e 0.50 Lead pitch b 0.17 - 0.27 Lead tip width Table 40. TQFP-64 package dimensions 21. Soldering Information The recommended soldering profiles for both leaded and Pb-free packages are according to IPC/JEDEC J-STD-020B, July 2002. |
|
