PA2423L-EK1

RangeCharger

TM 2.4 GHz BluetoothTM Power Amplifier Evaluation Kit

13-DST-03

Rev 2.3

Jan-18-2005

1 of 8

QA011805

Application

Bluetooth

TM

USB dongles

PCMCIA, flash cards

Access points

2.4 GHz cordless telephones

Features

Easy evaluation of the PA2423L Power Amplifier

Low Cost Design – 8 components required

Minimum board space required – 340 mils x 220

mils

High Output Power – 22.5 dBm

Schematic and layout ready for production builds

Lead free 6 pin QFN Package

Order Information

Part Number

Package

Remark

PA2423L

6 pin – QFN

Samples

PA2423L-R

6 pin – QFN

Tape & Reel

PA2423L-EK1

Evaluation Kit

Product Description

The PA2423L-EK1 evaluation kit provides an easy to

use, self-contained system for evaluating the RF

performance and DC parameters of the PA2423L

amplifier.

The PA2423L evaluation board requires minimal

board area and components and in addition, it has

been designed to allow the PA2423L to meet the

Bluetooth

tm

Class

1

wireless

technology

specifications, with particular attention to gain and

output power.

Each evaluation kit contains:

•

Pre-assembled evaluation board with input &

output

matching

networks.

Standard

SMA

connectors for interconnection to test equipment

•

A test report of the delivered board

•

A PA2423L datasheet

•

A PA2423L-EK1 data sheet

Functional Block Diagram

PA2423L

Header

GND

VRAMP

VCC

VCTL

SMA

Input

Match

Output

Match

PA2423L-EK1

EvaluationBoard

RFIN

RFOUT

Figure 1: PA2423L-EK1 Evaluation Board Block Diagram
