Philips Semiconductors

Product specification

Rectifier diodes

PBYL1025 series

Schottky barrier

FEATURES

SYMBOL

QUICK REFERENCE DATA

• Low forward volt drop

• Fast switching

V

• Reverse surge capability

• High thermal cycling performance

I

• Low thermal resistance

V

GENERAL DESCRIPTION

PINNING

SOD59 (TO220AC)

Schottky rectifier diodes intended

PIN

DESCRIPTION

for use as output rectifiers in low

voltage, high frequency switched

1

cathode

mode power supplies.

2

anode

The PBYL1025 series is supplied in

the

SOD59

(TO220AC)

tab

cathode

conventional leaded package.

LIMITING VALUES

Limiting values in accordance with the Absolute Maximum System (IEC 134)

SYMBOL PARAMETER

CONDITIONS

MIN.

MAX.

UNIT

PBYL10

20

25

V

RRM

Peak repetitive reverse

-

20

25

V

voltage

V

RWM

Working peak reverse

-

20

25

V

voltage

V

R

Continuous reverse voltage

T

-

20

25

V

I

F(AV)

Average rectified forward

square wave;

δ = 0.5; T

-

10

A

current

I

FRM

Repetitive peak forward

square wave;

δ = 0.5; T

-

20

A

current

I

FSM

Non-repetitive peak forward

t = 10 ms

-

135

A

current

t = 8.3 ms

-

150

A

sinusoidal; T

surge; with reapplied V

RRM(max)

I

RRM

Peak repetitive reverse

pulse width and repetition rate

-

1

A

surge current

limited by T

j max

T

j

Operating junction

-

150

˚C

temperature

T

stg

Storage temperature

- 65

175

˚C

k

a

12

1

tab

2

March 1998

1

Rev 1.000
