Zoran's HDM-R1 is a silicon efficient, cost effective intellectual

property core for IC designs requiring the HDMI Receive function. The

HDM-R1 decodes the HDMI standard into high definition digital video

formats (YCbCr or RGB) and multi-channel audio. High Definition

Content Protection (HDCP) decryption is supported. HDM-R1 includes

digital link, analog Phy and reference software to provide a complete

solution for the HDMI Receive function. HDM-R1 is proven in silicon.

Benefits Overview

HDM-R1 is a complete solution including the digital link layer and

analog Phy. Initially targeted to a TSMC 0.18 micron process,

HDM-R1 can be ported to other popular processes.

Digital Link and Analog PHY Solution

• HDMI version 1.1 compliant

• HDCP version 1.1 compliant

• Supports EIA/CEA 861b video formats including 480i, 480p, 576i,

576p, 720p, 1080i, and up to 1360 x 768

• Up to 8 channels uncompressed LPCM audio up to 192 kHz

• Pass through for compressed audio including Dolby Digital,

MPEG-2, MP-3, etc.MPEG-2, MP-3, etc.

• HDCP authentication and link verification

• Audio clock regeneration

• Video format detection

• Color space conversion

• Audio mute

• Internal color bar & square wave generators

• Generic Host Bus Interface for core configuration and control

• Onboard debug and test support

Features

• LCD Display Processors

• Digital TVs

• Set-top boxes

• DVD recorders

• A/V Receivers

• Any IC requiring the HDMI receive function

Integrated Circuit Applications

Digital Link

• Synthesizable RTL code (Verilog)

• Bit accurate C model

• Synopsis synthesis scripts

• Test bench with suite of test cases

Analog Phy

• GDS2

• CDL Netlist for LVS/DRC

• Verilog behavioural model (without timing)

• Synopsys .lib model

• Cadence .lef file (for integration and top level Place and Route).

• Cadence .tlf file (timing information for top level place and route)

• Layout recommendations/guidelines

• Package/PCB design recommendations

Deliverables

The HDM-R1 IP Core includes reference software which facilitates

the implementation, verification and validation of the core. It can

also be used as an example for further software system

development. Provided as source code, the reference software is

highly portable and can easily be adapted to any specific system.

The reference software consists of the following functions:

• Hardware configuration and system interface

• Authentication

Reference Software

DVD

Mobile

Digital TV

Imaging

IP Cores

Driving the Digital Lifestyle

Driving the Digital Lifestyle

02/06 -IN

HDMR1

HDM-R1

HDMI Receiver IP Core
